cisco access point

List of Latest cisco access point Models

Designed for Class I Division 2 hazardous locations
Intelligence with intent-based networking to the IoT Edge and IOx support
Partner IoT modules for WirelessHART  ISA100
Cisco DNA Assurance for network management
802.11ac Wave 1 and 2 capabilities

 2x2 MIMO with two spatial streams
 Multi- and single-user MIMO
 Maximal-Ratio Combining (MRC)
  802.11ac beamforming (transmit beamforming)
  20- 40- and 80-MHz channels
  PHY data rates up to 867 Mbps (80-MHz bandwidth in 5 GHz)
  Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
  802.11 Dynamic Frequency Selection (DFS)
  Cyclic Shift Diversity (CSD) support


802.11n Version 2.0 (and related) capabilities
  2x2 MIMO with two spatial streams
  Maximal-Ratio Combining (MRC)
  20- and 40-MHz channels
  PHY data rates up to 300 Mbps (40-MHz bandwidth in 5 GHz)
  Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
  802.11 Dynamic Frequency Selection (DFS)
  Cyclic Shift Diversity (CSD) support


Data rates supported
2.4-GHz radio:
802.11b: 1  2  5.5  11 Mbps
802.11g: 6  9  12  18  24  36  48  54 Mbps
802.11n data rates:

Interfaces
 x1 10/100/1000BASE-T autosensing PoE+ In (802.3at)UPOE in
  x2 10/100/1000BASE-T autosensing PoE Out (802.3af) PoE+ out (802.3at)
  x1 fiber SFP (fiber or electrical)
  Management console port (RJ-45)
  USB3.0 port
  Multicolor system LED  port LED
  DC power input (IW-6300H-DC-X-K9  IW-6300H-DCW-X-K9)
  AC power input (IW-6300H-AC-X-K9)
  Reset button

Uplink options
Ethernet  SFP  and wireless mesh

Dimensions (W x L x H)
IW-6300H-DC-X-K9: 9.7" x 11" x 3.8"
IW-6300H-DCW-X-K9: 9.7" x 11" x 5.6"
IW-6300H-AC-X-K9: 9.7" x 11" x 5.6"

Weight
13.3 lbs (IW-6300H-AC-X-K9), 9.8 lbs (IW-6300H-DC-X-K9),
12.7 lbs (IW-6300H-DCW-X-K9)

Warranty
1 year

IW 6300 Series
  IW-6300H-DC-X-K9: Dual-band 802.11a/g/n/ac  Wave 2  external antennas  44-57VDC/POE+/UPOE power input
  IW-6300H-DCW-X-K9: Dual-band 802.11a/g/n/ac  Wave 2  external antennas  10.8-36VDC/POE+/UPOE power input
  IW-6300H-AC-X-K9: Dual-band 802.11a/g/n/ac  Wave 2  external antennas  110-220VAC/POE+/UPOE power input
  • Four radios: 2.4 GHz (4x4) 5 GHz (8x8 and 4x4) Cisco RF ASIC, and BLE/IoT
  • Cisco Flexible Radio Assignment and Cisco CleanAir Technology
  • Internal and external antenna
  • WiFi 6 certified
  • Software: Catalyst 9130 AXI: Cisco Unified Wireless Network Software Release 8.10.x or later
  • Cisco IOS XE Software Release 16.12.1 with AP Device Pack or later
  • Catalyst 9130AXE: Cisco Unified Wireless Network Software Release 8.10MR1 or later
  • Cisco IOS XE Software Release 17.1.1 s or later
  • Supported wireless LAN controllers: Cisco Catalyst 9800 Series Wireless Controllers
  • Cisco 3504 5520 and 8540 Wireless Controllers and Cisco Virtual Wireless Controller
  • 802.11n version 2.0 (and related) capabilities
  • 4x4 MIMO with four spatial streams
  • Maximal Ratio Combining (MRC)
  • 802.11n and 802.11a/g
  • 20- and 40 MHz channels
  • PHY data rates up to 1.5 Gbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)
  • Packet aggregation: Aggregate MAC Protocol Data Unit (A-MPDU) (transmit and receive) Aggregate MAC Service Data Unit (A-MSDU) (transmit and receive)
  • 802.11 Dynamic Frequency Selection (DFS)
  • Cyclic Shift Diversity (CSD) support
  • 802.11ac
  • 8x8 downlink MU-MIMO with eight spatial streams
  • MRC
  • 802.11ac beamforming
  • 20- 40- 80- and 160-MHz channels
  • PHY data rates up to 6.9 Gbps (160 MHz with 5 GHz)
  • Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
  • 802.11 DFS
  • CSD support
  • WPA3 support
  • 802.11ax
  • 8x8 uplink/downlink MU-MIMO with eight spatial streams
  • Uplink/downlink OFDMA
  • TWT
  • BSS coloring
  • MRC
  • 802.11ax beamforming
  • 20- 40- 80- and 160-MHz channels
  • PHY data rates up to 10 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)
  • Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
  • 802.11 DFS
  • CSD support
  • WPA3 support
  • System memory: 2048 MB DRAM 1024 MB flash
  • Interfaces
  • 1x 100 1000 2500 5000 Multigigabit Ethernet (RJ-45) – IEEE 802.3az
  • Management console port (RJ-45)
  • USB 2.0 at 4.5W (enabled via future software)
  • Dimensions (W x L x H)
  • Access point (without mounting brackets):
  • C9130AXI: 8.9 x 8.9 x 1.88 in. (22.6 x 22.6 x 4.8 cm)
  • C9130AXE: 9.17 x 9.17 x 1.58 in. (23.3 x 23.3 x 4.0 cm)
  • Weight: Cisco Catalyst 9130AXI 3.2 lb. (1.45 kg)
  • Cisco Catalyst 9130AXE 3.78 lb. (1.71 kg)
  • Warranty: Limited lifetime hardware warranty
  • Four radios: 2.4 GHz (4x4) 5 GHz (4x4) Cisco RF ASIC and BLE/IoT
  • Cisco Flexible Radio Assignment and Cisco CleanAir Technology
  • Internal and external antenna
  • Software
  • Cisco Unified Wireless Network Software Release 8.9.x or later
  • Cisco IOS XE Software Release 16.11 with AP Device Pack or later
  • Supported wireless LAN controllers
  • Cisco Catalyst 9800 Series Wireless Controllers
  • Cisco 3500 5520 and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller
  • 802.11n version 2.0 (and related) capabilities
  • 4x4 MIMO with four spatial streams
  • Maximal Ratio Combining (MRC)
  • 802.11n and 802.11a/g beamforming
  • 20- and 40-MHz channels
  • PHY data rates up to 890 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)
  • Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
  • 802.11 Dynamic Frequency Selection (DFS)
  • Cyclic Shift Diversity (CSD) support
  • 802.11ac
  • 4x4 downlink MU-MIMO with four spatial streams
  • MRC
  • 802.11ac beamforming
  • 20- 40- 80- and 160-MHz channels
  • PHY data rates up to 3.47 Gbps (160 MHz with 5 GHz)
  • Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
  • 802.11 DFS
  • CSD support
  • 802.11ax
  • 4x4 downlink MU-MIMO with four spatial streams
  • Uplink/downlink OFDMA
  • TWT
  • BSS coloring
  • MRC
  • 802.11ax beamforming
  • 20- 40- 80- and 160-MHz channels
  • PHY data rates up to 5.38 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)
  • Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
  • 802.11 DFS
  • CSD support
  • Interfaces: 1x 100 1000 2500 Multigigabit Ethernet (RJ-45)IEEE 802.3bz
  • Management console port (RJ-45) USB 2.0 3.75W (enabled via future software)
  • Indicators: Status LED indicates boot loader status association status operating status boot loader warnings and boot loader errors
  • Dimensions (W x L x H)
  • Access point (without mounting brackets): C9120I: 8.5 x 8.5 x 1.7 (21.6 x 21.6 x 4.3 cm) C9120E and C9120P: 8.5 x 8.05x 2.0 (21.6 x 21.6 x 5.1 cm)
  • Weight: Cisco Catalyst 9120I 2.87 lbs (1.3 kg)
  • Cisco Catalyst 9120E/P 3 lbs (1.36 kg)
  • System memory: 2048 MB DRAM 1024 MB flash
  • Warranty: Limited lifetime hardware warranty
  • Three radios: 2.4GHz (4x4) 5GHz (8x8) and BLE Supports OFDMA and MU-MIMO Internal antenna
  • Software: Cisco Unified Wireless Network Software Release 8.9 or later
  • Cisco IOS XE Software Release 16.11 or later
  • Supported wireless LAN controllers: Cisco Catalyst 9800 Series Wireless Controllers
  • Cisco 3500 5520 and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller
  • 802.11n version 2.0 (and related) capabilities
  • 8x8 MIMO with four spatial streams for 5 GHz band
  • 4x4 MIMO with four spatial streams for 2.4 GHz band
  • Maximal Ratio Combining (MRC)
  • 20- and 40-MHz channels
  • PHY data rates up to 600 Mbps (40 MHz with 5 GHz)
  • Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
  • Cyclic Shift Diversity (CSD) support
  • 802.11ac
  • 8x8 downlink MU-MIMO with eight spatial streams
  • MRC
  • 802.11ac beamforming
  • 20- 40- 80 and 160 MHz channels
  • PHY data rates up to 3.5 Gbps at 5 GHz
  • Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
  • CSD support
  • 160 MHz support only on 4 spatial stream
  • 802.11ax
  • 8x8 MIMO with eight spatial streams for 5-GHz band
  • 4x4 MIMO with four spatial streams for 2.4-GHz band
  • Downlink OFDMA
  • TWT
  • MRC
  • 802.11ax beamforming
  • 20- 40- 80 and 160 MHz channels
  • PHY data rates up to 5 Gbps at 5 GHz
  • Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
  • CSD support
  • Integrated antenna: 2.4 GHz peak gain 4 dBi internal antenna omnidirectional in azimuth
  • 5 GHz peak gain 6 dBi internal antenna omnidirectional in azimuth
  • Interfaces: 1x 100 1000 2500 5000 Multigigabit Ethernet (RJ-45)IEEE 802.3bz
  • Management console port (RJ-45)
  • USB 2.0 with up to 4.5W (enabled via future software)
  • Indicators: Status LED indicates boot loader status association status operating status boot loader warnings and boot loader errors
  • Dimensions (W x L x H)
  • Access point (without mounting bracket and mounting features): 8.70 x 8.70 x 1.94 in. (22 x 22 x 4.93 cm)
  • Access point (without mounting bracket): 8.70 x 8.70 x 2.19 in. (22 x 22 x 5.56 cm)
  • Weight: 3.02 lb (1.4 kg)
  • System memory: 2048 MB DRAM 1024 MB flash
  • Warranty: Limited lifetime hardware warranty
  • Three radios: 2.4GHz (4x4) 5GHz (4x4) and BLE Supports OFDMA and MU-MIMO Internal and external antenna
  • Software: Cisco Unified Wireless Network Software Release 8.9 or later
  • Cisco IOS XE Software Release 16.11 or later
  • Supported wireless LAN controllers: Cisco Catalyst 9800 Series Wireless Controllers
  • Cisco 3500 5520 and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller
  • 802.11n version 2.0 (and related) capabilities
  • 4x4 MIMO with four spatial streams
  • Maximal Ratio Combining (MRC)
  • 802.11n and 802.11a/g beamforming
  • 20- and 40-MHz channels
  • PHY data rates up to 890 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)
  • Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
  • 802.11 Dynamic Frequency Selection (DFS)
  • Cyclic Shift Diversity (CSD) support
  • 802.11ac
  • 4x4 downlink MU-MIMO with four spatial streams
  • MRC
  • 802.11ac beamforming
  • 20- 40- 80- and 160-MHz channels
  • PHY data rates up to 3.47 Gbps (160 MHz with 5 GHz)
  • Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
  • 802.11 DFS
  • CSD support
  • 802.11ax
  • 4x4 downlink MU-MIMO with four spatial streams
  • Uplink/downlink OFDMA
  • TWT
  • BSS coloring
  • MRC
  • 802.11ax beamforming
  • 20- 40- 80- and 160-MHz channels
  • PHY data rates up to 5.38 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)
  • Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
  • 802.11 DFS
  • CSD support
  • Integrated antenna: 2.4 GHz peak gain 3 dBi internal antenna omnidirectional in azimuth
  • 5 GHz peak gain 4 dBi internal antenna omnidirectional in azimuth
  • External antenna (sold separately)
  • Cisco Catalyst 9115AXE Access Points are certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz)
  • Cisco offers the industry's broadest selection of antennas delivering optimal coverage for a variety of deployment scenarios
  • Interfaces: 1x 100 1000 2500 Multigigabit Ethernet (RJ-45) – IEEE 802.3bz
  • Management console port (RJ-45) USB 2.0 (enabled via future software)
  • Indicators: Status LED indicates boot loader status association status operating status boot loader warnings and boot loader errors
  • Dimensions (W x L x H)
  • Access point (without mounting brackets): C9115I: 8.0 x 8.0 x 1.5 in. (20.3 x 20.3 x 3.8 cm) C9115E: 8.0 x 8.0 x 1.7 in. (20.3 x 20.3 x 4.3 cm)
  • Weight: Cisco Catalyst 9115AXI 1.98 lb (0.9 kg)
  • Cisco Catalyst 9115AXE 2.43 lb (1.1 kg)
  • System memory: 2048 MB DRAM 1024 MB flash
  • Warranty: Limited lifetime hardware warranty
Embed resilient Cisco WiFi into your hardware.
Extend intent-based networking to your solutions .
IOx support for intelligence at the edge.
Cisco DNA Assurance for worry-free network management.

Radio type
2.4 GHz: 802.11b/g/n  2x2 MIMO  2 spatial streams
5 GHz: 802.11a/n/ac  2x2 MIMO  2 spatial streams

802.11ac Wave 2 capabilities
 2x2 MIMO with two spatial streams
  Multi- and single-user MIMO
  Maximal-Ratio Combining (MRC)
  802.11ac beamforming (transmit beamforming)
  20- 40- and 80-MHz channels
  PHY data rates up to 867 Mbps (80-MHz bandwidth in 5 GHz)
  Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
  802.11 Dynamic Frequency Selection (DFS)
  Cyclic Shift Diversity (CSD) support

802.11n Version 2.0 (and related) capabilities
  2x2 MIMO with two spatial streams
  Maximal-Ratio Combining (MRC)
  20- and 40-MHz channels
  PHY data rates up to 300 Mbps (40-MHz bandwidth in 5 GHz)
  Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
  802.11 Dynamic Frequency Selection (DFS)
 Cyclic Shift Diversity (CSD) support

Data rates supported
2.4-GHz radio:
802.11b: 1  2  5.5  11 Mbps
802.11g: 6  9  12  18  24  36  48  54 Mbps
802.11n data rates:

Interfaces
 x1 10/100/1000BASE-T auto-sensing PoE+ in (802.3at)Cisco Universal Power over Ethernet (UPOE) in
  x2 10/100/1000BASE-T auto-sensing PoE out (802.3af) PoE+ out (802.3at)
  x1 fiber SFP (fiber or electrical)
  Management console port (RJ-45)
  USB 3.0 port
  Multicolor system LED  port LED
  DC power input
  Reset button

Uplink options
Ethernet  SFP  and wireless mesh

Antennas :Dual band

PoE output : 35.3 W total
Maximum 30W per PSE port

USB interface
USB 2.0 / USB 3.0 supported

Dimensions (H x W x L)
8.5 in. x 7.55 in. x 1.9 in.

Weight
3.1 lbs.

Warranty
1 year
Industrial  outdoor 802.11ac wireless.
Designed and certified for extreme environments.
Rail - rolling stock  shock and vibration certified.
Chipset with best-in-class RF architecture.

Software
Cisco Unified Wireless Network Software Release with AireOS Wireless Controllers:
8.0.120.0 or later for the Cisco IW3700 Series Access Point
Cisco IOS Software Release
 15.3(3)JA5 or later for the Cisco IW3700 Series Access Point

802.11ac Wave 1 capabilities

  4 x 4 MIMO with 3 spatial streams
  Maximal-Ratio Combining (MRC)
  802.11ac beamforming
  20- 40- and 80-MHz channels
  PHY data rates up to 1.3 Gbps (80 MHz with 5 GHz)
  Packet aggregation: A-MPDU (Tx/Rx) A-MSDU (Tx/Rx)
  802.11 Dynamic Frequency Selection (DFS)
  Cyclic Shift Diversity (CSD) support

802.11n version 2.0 (and related) capabilities

4 x 4 MIMO with 3 spatial streams
  Maximal-Ratio Combining (MRC)
 802.11n and 802.11a/g beamforming
  20- and 40-MHz channels
 PHY data rates up to 450 Mbps (40 MHz with 5 GHz)
 Packet aggregation: A-MPDU (Tx/Rx) A-MSDU (Tx/Rx)
 802.11 Dynamic Frequency Selection (DFS)
 Cyclic Shift Diversity (CSD) support

Data rates supported
802.11a: 6  9  12  18  24  36  48  and 54 Mbps
802.11g: 1  2  5.5  6  9  11  12  18  24  36  48  and 54 Mbps

Interfaces

 10/100/1000BASE-T autosensing (M12 8P female connector with X-coding per IEC 61076-2) PoE In (802.3af) PoE+ In (802.3at)
 10/100/1000BASE-T autosensing (M12 8P female connector with X-coding per IEC 61076-2) PoE Out (802.3af)
 Management console port (serial with RJ-45 connector)

Indicators
 Status LED indicates boot loader status  association status  operating status  boot loader warnings  boot loader errors

System memory
 512 MB DRAM
 64 MB flash

Dimensions (W x L x H)
 Access point (not including connectors): 11.3 x 8.0 x 2.3 in (28.7 x 20.3 x 5.9 cm)
 Volume: 148 cubic inches (2.4 liters)

Weight
  6.7 lb (3.0 kg)

Warranty
5-year limited hardware warranty
