sonic firewall

List of Latest sonic firewall Models

Firewall general :
  • Operating system : SonicOS 6.5.1
  • Security processing cores : 24
Interfaces :
  • 4 x 10-GbE SFP+,
  • 8 x 1-GbE SFP,
  • 8 x 1-GbE,
  • 1 GbE Management,
  • 1 Console
  • Expansion:1 Expansion Slot (Rear)*, SD Card*
  • Management :CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
  • SSO users:70,000
  • Maximum access points supported : 128
  • Logging : Analyzer, Local Log, Syslog

Firewall/VPN Performance:
  • Firewall inspection throughput : 12.0 Gbps
  • Full DPI throughput : 3.0 Gbps
  • Application inspection throughput : 4.5 Gbps
  • IPS throughput : 4.5 Gbps
  • Anti-malware inspection throughput : 3.0 Gbps
  • IMIX throughput : 3.5 Gbps
  • TLS/SSL decryption and inspection (DPI SSL) : 1.3 Gbps
  • VPN throughput : 5.0 Gbps
  • Connections per second : 90,000/sec
  • Maximum connections (SPI) : 1,500,000
  • Maximum connections (DPI) : 1,000,000
  • Default/Maximum connections (DPI SSL) : 6,000/10,500

VPN :
  • Site-to-site VPN tunnels : 6,000
  • IPSec VPN clients (max) : 2,000 (6,000)
  • SSL VPN NetExtender clients (max) : 2 (1,500)
  • Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
  • Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
  • Route-based VPN : RIP, OSPF, BGP

Networking :
  • IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
  • NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
  • VLAN interfaces : 256
  • Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
  • QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
  • Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
  • VoIP : Full H323-v1-5, SIP
  • Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
  • Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
  • High availability : Active/Passive with State Sync, Active/Active DPI with State Sync, Active/Active Clustering

Hardware :
  • Power supply : Single, Fixed 250W
  • Fans : Dual, redundant, hot swappable
  • Input power : 100-240 VAC, 60-50 Hz
  • Maximum power consumption (W) : 113.1
  • MTBF @25ºC in hours : 116,477
  • MTBF @25ºC in years : 13.30
  • Form factor : 1U Rack Mountable
  • Dimensions : 1.75 x 19.1 x 17 in (4.5 x 48.5 x 43 cm)
  • Weight : 14.93 lb (6.77 kg)
  • WEEE weight : 19.78 lb (8.97 kg)
  • Shipping weight : 26.12 lb (11.85 kg)
  • Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
  • Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
  • Humidity : 10-90% non-condensing
Firewall general :
  • Operating system : SonicOS 6.5.1
  • Security processing cores : 10
Interfaces :
  • 2 x 10-GbE SFP+,
  • 4 x 1-GbE SFP,
  • 12 x 1-GbE,
  • 1 GbE Management,
  • 1 Console
  • Expansion:1 Expansion Slot (Rear)*, SD Card*
  • Management : CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
  • SSO users : 60,000
  • Maximum access points supported : 96
  • Logging : Analyzer, Local Log, Syslog
Firewall/VPN Performance:
  • Firewall inspection throughput : 9.0 Gbps
  • Full DPI throughput : 1.6 Gbps
  • Application inspection throughput : 3.0 Gbps
  • IPS throughput : 3.0 Gbps
  • Anti-malware inspection throughput : 1.7 Gbps
  • IMIX throughput : 2.4 Gbps
  • TLS/SSL decryption and inspection (DPI SSL) :  800 Mbps
  • VPN throughput : 4.5 Gbps
  • Connections per second : 60,000/sec
  • Maximum connections (SPI) : 1,500,000
  • Maximum connections (DPI) : 1,000,000
  • Default/Maximum connections (DPI SSL) : 4,000/8,500
VPN :
  • Site-to-site VPN tunnels : 4,000
  • IPSec VPN clients (max) : 2,000 (4,000)
  • SSL VPN NetExtender clients (max) : 2 (1,000)
  • Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
  • Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
  • Route-based VPN : RIP, OSPF, BGP
Networking :
  • IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
  • NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
  • VLAN interfaces : 400
  • Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
  • QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
  • Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
  • VoIP : Full H323-v1-5, SIP
  • Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
  • Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
  • High availability : Active/Passive with State Sync, Active/Active DPI with State Sync, Active/Active Clustering

Hardware :
  • Power supply : Single, Fixed 250W
  • Fans : Dual, Fixed
  • Input power : 100-240 VAC, 60-50 Hz
  • Maximum power consumption (W) : 90.9
  • MTBF @25ºC in hours : 134,900
  • MTBF @25ºC in years : 15.40
  • Form factor : 1U Rack Mountable
  • Dimensions : 1.75 x 19.1 x 17 in (4.5 x 48.5 x 43 cm)
  • Weight : 13.56 lb (6.15 kg)
  • WEEE weight : 14.24 lb (6.46 kg)
  • Shipping weight : 20.79lb (9.43 kg)
  • Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
  • Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
  • Humidity : 10-90% non-condensing
Firewall general :
  • Operating system : SonicOS 6.5.1
  • Security processing cores : 8
Interfaces :
  • 2 x 10-GbE SFP+,
  • 4 x 1-GbE SFP,
  • 12 x 1-GbE,
  • 1 GbE Management,
  • 1 Console
  • Expansion:1 Expansion Slot (Rear)*, SD Card*
  • Management : CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
  • SSO users : 50,000
  • Maximum access points supported : 64
  • Logging : Analyzer, Local Log, Syslog
Firewall/VPN Performance:
  • Firewall inspection throughput : 6.0 Gbps
  • Full DPI throughput : 800 Mbps
  • Application inspection throughput : 2.0 Gbps
  • IPS throughput : 2.0 Gbps
  • Anti-malware inspection throughput : 1.1 Gbps
  • IMIX throughput : 1.6 Gbps
  • TLS/SSL decryption and inspection (DPI SSL) :  500 Mbps
  • VPN throughput : 3.0 Gbps
  • Connections per second : 40,000/sec
  • Maximum connections (SPI) : 1,000,000
  • Maximum connections (DPI) : 500,000
  • Default/Maximum connections (DPI SSL) : 3,000/4,500
VPN :
  • Site-to-site VPN tunnels : 3,000
  • IPSec VPN clients (max) : 500 (3,000)
  • SSL VPN NetExtender clients (max) : 2 (500)
  • Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
  • Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
  • Route-based VPN : RIP, OSPF, BGP
Networking :
  • IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
  • NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
  • VLAN interfaces : 256
  • Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
  • QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
  • Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
  • VoIP : Full H323-v1-5, SIP
  • Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
  • Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
  • High availability : Active/Passive with State Sync, Active/Active Clustering
Hardware :
  • Power supply : Single, Fixed 250W
  • Fans : Dual, Fixed
  • Input power : 100-240 VAC, 60-50 Hz
  • Maximum power consumption (W) : 86.7
  • MTBF @25ºC in hours : 139,783
  • MTBF @25ºC in years : 15.96
  • Form factor : 1U Rack Mountable
  • Dimensions : 1.75 x 19.1 x 17 in (4.5 x 48.5 x 43 cm)
  • Weight : 13.56 lb (6.15 kg)
  • WEEE weight : 14.24 lb (6.46 kg)
  • Shipping weight : 20.79lb (9.43 kg)
  • Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
  • Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
  • Humidity : 10-90% non-condensing
Firewall general :
  • Operating system : SonicOS 6.5.1
  • Security processing cores : 6
Interfaces :
  • 2 x 10-GbE SFP+,
  • 4 x 1-GbE SFP,
  • 12 x 1-GbE,
  • 1 GbE Management,
  • 1 Console
  • Expansion:1 Expansion Slot (Rear)*, SD Card*
  • Management : CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
  • SSO users : 40,000
  • Maximum access points supported : 48
  • Logging : Analyzer, Local Log, Syslog

Firewall/VPN Performance:
  • Firewall inspection throughput : 3.4 Gbps
  • Full DPI throughput : 500 Mbps
  • Application inspection throughput : 1.1 Gbps
  • IPS throughput : 1.1 Gbps
  • Anti-malware inspection throughput :  600 Mbps
  • IMIX throughput : 900 Mbps
  • TLS/SSL decryption and inspection (DPI SSL) :  300 Mbps
  • VPN throughput : 1.5 Gbps
  • Connections per second : 20,000/sec
  • Maximum connections (SPI) : 750,000
  • Maximum connections (DPI) : 375,000
  • Default/Maximum connections (DPI SSL) : 2,000/2,750

VPN :
  • Site-to-site VPN tunnels : 1,000
  • IPSec VPN clients (max) : 50 (1,000)
  • SSL VPN NetExtender clients (max) : 2 (350)
  • Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
  • Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
  • Route-based VPN : RIP, OSPF, BGP

Networking :
  • IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
  • NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
  • VLAN interfaces : 256
  • Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
  • QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
  • Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
  • VoIP : Full H323-v1-5, SIP
  • Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
  • Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
  • High availability : Active/Passive with State Sync, Active/Active Clustering

Hardware :
  • Power supply : Single, Fixed 250W
  • Fans : Dual, Fixed
  • Input power : 100-240 VAC, 60-50 Hz
  • Maximum power consumption (W) : 74.3
  • MTBF @25ºC in hours : 146,789
  • MTBF @25ºC in years : 16.76
  • Form factor : 1U Rack Mountable
  • Dimensions : 1.75 x 19.1 x 17 in (4.5 x 48.5 x 43 cm)
  • Weight : 13.56 lb (6.15 kg)
  • WEEE weight : 14.24 lb (6.46 kg)
  • Shipping weight : 20.79lb (9.43 kg)
  • Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
  • Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
  • Humidity : 10-90% non-condensing
Firewall general :
  • Operating system : SonicOS 6.5.1
  • Security processing cores : 4
Interfaces :
  • 8 x 1-GbE,
  • 1 GbE Management,
  • 1 Console
  • Expansion:1 Expansion Slot (Rear)*, SD Card*
  • Management : CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
  • SSO users : 30,000
  • Maximum access points supported : 32
  • Logging : Analyzer, Local Log, Syslog
Firewall/VPN Performance:
  • Firewall inspection throughput : 1.9 Gbps
  • Full DPI throughput : 300 Mbps
  • Application inspection throughput : 700 Mbps
  • IPS throughput : 700 Mbps
  • Anti-malware inspection throughput :  400 Mbps
  • IMIX throughput : 600 Mbps
  • TLS/SSL decryption and inspection (DPI SSL) :  200 Mbps
  • VPN throughput : 1.1 Gbps
  • Connections per second : 15,000/sec
  • Maximum connections (SPI) : 500,000
  • Maximum connections (DPI) : 250,000
  • Default/Maximum connections (DPI SSL) : 1,000/1,000
VPN :
  • Site-to-site VPN tunnels : 250
  • IPSec VPN clients (max) : 10 (250)
  • SSL VPN NetExtender clients (max) : 2 (250)
  • Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
  • Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
  • Route-based VPN : RIP, OSPF, BGP
Networking :
  • IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
  • NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
  • VLAN interfaces : 256
  • Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
  • QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
  • Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
  • VoIP : Full H323-v1-5, SIP
  • Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
  • Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
  • High availability : Active/Passive with State Sync
Hardware :
  • Power supply : Single, Fixed 200W
  • Fans : Dual, Fixed
  • Input power : 100-240 VAC, 60-50 Hz
  • Maximum power consumption (W) : 49.4
  • MTBF @25ºC in hours : 176,540
  • MTBF @25ºC in years : 20.15
  • Form factor : 1U Rack Mountable
  • Dimensions : 1.75 x 10.25 x 17 in(4.5 x 26 x 43 cm)
  • Weight : 10.1 lb (4.6 kg)
  • WEEE weight : 11.0 lb (5.0 kg)
  • Shipping weight : 14.3 lb (6.5 kg)
  • Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
  • Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
  • Humidity : 10-90% non-condensing
Performance Overview:
  • Operating system : SonicOS 5.9.x – Wired / SonicOS 6.2.x – Wireless
  • Security Processor: 2x400 MHz (Wired) / 2x800 MHz (Wireless)
  • Memory (RAM): 512 MB (Wired) /1 GB (Wireless)
  • 1 GbE Copper interfaces : 5
  • Expansion : USB
  • Firewall inspection throughput: 300 Mbps
  • Full DPI throughput:50 Mbps
  • Application inspection throughput:0
  • IPS throughput : 100 Mbps
  • Anti-malware inspection throughput : 50 Mbps
  • IMIX throughput : 60 Mbps
  • SSL Inspection and Decryption (DPI SSL) :15 Mbps
  • VPN throughput : 100 Mbps
  • Connections per second : 1,800
  • Maximum connections (SPI) : 10,000
  • Maximum connections (DPI) : 10,000
  • Single Sign-On (SSO) Users  :250
  • VLAN interfaces : 25
  • SonicPoints supported (Maximum) : 2

VPN :
  • Site-to-Site VPN Tunnels : 10
  • IPSec VPN clients (Maximum) : 1 (5)
  • SSL VPN licenses (Maximum) : 1 (10)
  • Virtual assist bundled (Maximum) : No
  • Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
  • Key exchange : Diffie Hellman Groups 1, 2, 5, 14
  • Route-based VPN : RIP, OSPF
  • Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
  • VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
  • Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
  • NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
  • Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)

Security Services:
  • Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
  • Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
  • Enforced Client Anti-Virus and Anti-Spyware : McAfee®
  • Comprehensive Anti-Spam Service : Supported
  • Application Intelligence and Control : Yes
  • Application Visualization : No
Networking:
  • IP address assignment :  Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
  • NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
  • Routing protocols : OSPF, RIPv1/v2, static routes, policy-based routing, multicast
  • QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
  • Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
  • Local user database : 150
  • VoIP : Full H.323v1-5, SIP
  • Standards  : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
  • Certifications : VPNC, IPv6 (Phase 2)
  • Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
  • Common Access Card (CAC) : Supported
  • High Availability : No
Hardware:
  • Form factor : Desktop
  • Power Supply (W) : 24W external
  • Maximum power consumption (W) : 6.4 / 11.3
  • Input power : 100 to 240 VAC, 50-60 Hz, 1 A
  • Total heat dissipation : 21.8 / 38.7 BTU
  • Dimensions : 3.6x14.1x19cm
  • Weight : 0.34 Kg / 0.75 lbs & 0.48 Kg / 1.06 lbs
  • WEEE weight : 0.80 Kg / 1.76 lbs & 0.94 Kg / 2.07 lbs
  • Shipping weight : 1.20 Kg / 2.64 lbs & 1.34 Kg / 2.95 lbs
  • MTBF (Years) : 30 / 15
  • Environment : 40-105° F, 0-40° C
  • Humidity : 5-95% non-condensing
Performance Overview:
  • Operating system : SonicOS 6.2.x
  • Security Processor:  2x 800 MHz
  • Memory (RAM): 1 GB
  • 1 GbE Copper interfaces : 5
  • Expansion : USB
  • Firewall inspection throughput: 750 Mbps
  • Full DPI throughput:100 Mbps
  • Application inspection throughput:300 Mbps
  • IPS throughput : 300 Mbps
  • Anti-malware inspection throughput : 100 Mbps
  • IMIX throughput : 200 Mbps
  • SSL Inspection and Decryption (DPI SSL) :45 Mbps
  • VPN throughput : 300 Mbps
  • Connections per second : 5,000
  • Maximum connections (SPI) : 50,000
  • Maximum connections (DPI) : 50,000
  • Single Sign-On (SSO) Users  :500
  • VLAN interfaces : 25
  • SonicPoints supported (Maximum) : 8
VPN :
  • Site-to-Site VPN Tunnels : 10
  • IPSec VPN clients (Maximum) : 1 (10)
  • SSL VPN licenses (Maximum) : 1 (50)
  • Virtual assist bundled (Maximum) : 1 (30-day trial)
  • Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
  • Key exchange : Diffie Hellman Groups 1, 2, 5, 14
  • Route-based VPN : RIP, OSPF
  • Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
  • VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
  • Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
  • NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
  • Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)

Security Services:
  • Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
  • Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
  • Enforced Client Anti-Virus and Anti-Spyware : McAfee®
  • Comprehensive Anti-Spam Service : Supported
  • Application Intelligence and Control : Yes
  • Application Visualization : Yes
Networking:
  • IP address assignment :  Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
  • NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
  • Routing protocols : OSPF, RIPv1/v2, static routes, policy-based routing, multicast
  • QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
  • Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
  • Local user database : 150
  • VoIP : Full H.323v1-5, SIP
  • Standards  : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
  • Certifications : VPNC, IPv6 (Phase 2)
  • Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
  • Common Access Card (CAC) : Supported
  • High Availability : Active/Standby
Hardware:
  • Form factor : Desktop
  • Power Supply (W) : 24W external
  • Maximum power consumption (W) : 6.9 / 12.0
  • Input power : 100 to 240 VAC, 50-60 Hz, 1 A
  • Total heat dissipation : 23.5 / 40.9 BTU
  • Dimensions : 3.5x13.4x19cm
  • Weight : 0.73 Kg / 1.61 lbs & 0.84 Kg / 1.85 lbs
  • WEEE weight : 1.15 Kg / 2.53 lbs & 1.26 Kg / 2.78 lbs
  • Shipping weight : 1.37 Kg / 3.02 lbs & 1.48 Kg / 3.26 lbs
  • MTBF (Years) : 28 / 14
  • Environment : 40-105° F, 0-40° C
  • Humidity : 5-95% non-condensing
Performance Overview:
  • Security Processor: 4x 800 MHz
  • Memory (RAM): 1 GB
  • 1 GbE Copper interfaces : 7
  • Expansion : USB
  • Firewall inspection throughput: 1.3 Gbps
  • Full DPI throughput:300Mbps
  • Application inspection throughput:900Mbps
  • IPS throughput : 900Mbps
  • Anti-malware inspection throughput : 300Mbps
  • IMIX throughput :  500Mbps
  • SSL Inspection and Decryption (DPI SSL) : 100Mbps
  • VPN throughput : 900 Mbps
  • Connections per second : 6,000
  • Maximum connections (SPI) : 100,000
  • Maximum connections (DPI) : 90,000
  • Single Sign-On (SSO) Users  :500
  • VLAN interfaces : 50
  • SonicPoints supported (Maximum) : 16
VPN :
  • Site-to-Site VPN Tunnels : 20
  • IPSec VPN clients (Maximum) : 2 (25)
  • SSL VPN licenses (Maximum) : 2 (100)
  • Virtual assist bundled (Maximum) : 1 (30-day trial)
  • Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
  • Key exchange : Diffie Hellman Groups 1, 2, 5, 14
  • Route-based VPN : RIP, OSPF
  • Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
  • VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
  • Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
  • NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
  • Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)
Security Services:
  • Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
  • Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
  • Enforced Client Anti-Virus and Anti-Spyware : McAfee®
  • Comprehensive Anti-Spam Service : Supported
  • Application Intelligence and Control : Yes
  • Application Visualization : Yes
Networking:
  • IP address assignment :  Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
  • NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
  • Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing, multicast
  • QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
  • Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
  • Local user database : 250
  • VoIP : Full H.323v1-5, SIP
  • Standards  : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
  • Certifications : VPNC, IPv6 (Phase 2)
  • Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
  • Common Access Card (CAC) : Supported
  • High Availability : Active/Standby
Hardware:
  • Form factor : Desktop
  • Power Supply (W) : 24W external
  • Maximum power consumption (W) : 9.2 / 13.8
  • Input power : 100 to 240 VAC, 50-60 Hz, 1 A
  • Total heat dissipation : 31.3 / 47.1 BTU
  • Dimensions : 3.6x14.1x19cm
  • Weight : 0.73 Kg / 1.61 lbs & 0.84 Kg / 1.85 lbs
  • WEEE weight : 1.15 Kg / 2.53 lbs & 1.26 Kg / 2.78 lbs
  • Shipping weight : 1.37 Kg / 3.02 lbs & 1.48 Kg / 3.26 lbs
  • MTBF (Years) : 27 / 13
  • Environment : 40-105° F, 0-40° C
  • Humidity : 5-95% non-condensing
Performance Overview:
  • Security Processor: 4x 1 GHz
  • Memory (RAM): 1 GB
  • 1 GbE Copper interfaces : 8
  • Expansion : USB
  • Firewall inspection throughput: 1.4 Gbps
  • Full DPI throughput: 400 Mbps
  • Application inspection throughput:1.0 Gbps
  • IPS throughput :  1.0 Gbps
  • Anti-malware inspection throughput :  400 Mbps
  • IMIX throughput :  700 Mbps
  • SSL Inspection and Decryption (DPI SSL) :150 Mbps
  • VPN throughput : 1.0 Gbps
  • Connections per second : 8,000
  • Maximum connections (SPI) : 125,000
  • Maximum connections (DPI) : 100,000
  • Single Sign-On (SSO) Users  : 500
  • VLAN interfaces : 50
  • SonicPoints supported (Maximum) : 16
VPN :
  • Site-to-Site VPN Tunnels : 25
  • IPSec VPN clients (Maximum) :  2 (25)
  • SSL VPN licenses (Maximum) : 2 (150)
  • Virtual assist bundled (Maximum) : 1 (30-day trial)
  • Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
  • Key exchange : Diffie Hellman Groups 1, 2, 5, 14
  • Route-based VPN : RIP, OSPF
  • Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
  • VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
  • Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
  • NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
  • Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)
Security Services:
  • Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
  • Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
  • Enforced Client Anti-Virus and Anti-Spyware : McAfee®
  • Comprehensive Anti-Spam Service : Supported
  • Application Intelligence and Control : Yes
  • Application Visualization : Yes
Networking:
  • IP address assignment :  Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
  • NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
  • Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing, multicast
  • QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
  • Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
  • Local user database : 150
  • VoIP : Full H.323v1-5, SIP
  • Standards  : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
  • Certifications : VPNC, IPv6 (Phase 2)
  • Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
  • Common Access Card (CAC) : Supported
  • High Availability : Active/Standby with stateful synchronization
Hardware:
  • Form factor : Desktop
  • Power Supply (W) : 36W external
  • Maximum power consumption (W) : 13.4 / 17.7
  • Input power : 100 to 240 VAC, 50-60 Hz, 1 A
  • Total heat dissipation : 45.9 / 60.5 BTU
  • Dimensions : 3.5x15x22.5cm
  • Weight : 0.92 Kg / 2.03 lbs & 1.05 Kg / 2.31 lbs
  • WEEE weight : 1.34 Kg / 2.95 lbs & 1.48 Kg / 3.26 lbs
  • Shipping weight : 1.93 Kg / 4.25 lbs & 2.07 Kg / 4.56 lbs
  • MTBF (Years) : 20 / 12
  • Environment : 40-105° F, 0-40° C
  • Humidity : 5-95% non-condensing
Performance Overview:
  • Security Processor: 4x 1.4 GHz
  • Memory (RAM): 1 GB
  • 1 GbE Copper interfaces : 10
  • Expansion : Expansion Slot (Rear), 2 USB
  • Firewall inspection throughput: 1.5 Gbps
  • Full DPI throughput: 500 Mbps
  • Application inspection throughput:1.1 Gbps
  • IPS throughput :  1.1 Gbps
  • Anti-malware inspection throughput :  500 Mbps
  • IMIX throughput :  900 Mbps
  • SSL Inspection and Decryption (DPI SSL) :200 Mbps
  • VPN throughput : 1.1 Gbps
  • Connections per second : 12,000
  • Maximum connections (SPI) : 150,000
  • Maximum connections (DPI) : 125,000
  • Single Sign-On (SSO) Users  : 500
  • VLAN interfaces : 50
  • SonicPoints supported (Maximum) : 24
VPN :
  • Site-to-Site VPN Tunnels : 50
  • IPSec VPN clients (Maximum) :  2 (25)
  • SSL VPN licenses (Maximum) : 2 (200)
  • Virtual assist bundled (Maximum) : 1 (30-day trial)
  • Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
  • Key exchange : Diffie Hellman Groups 1, 2, 5, 14
  • Route-based VPN : RIP, OSPF
  • Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
  • VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
  • Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
  • NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
  • Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)
Security Services:
  • Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
  • Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
  • Enforced Client Anti-Virus and Anti-Spyware : McAfee®
  • Comprehensive Anti-Spam Service : Supported
  • Application Intelligence and Control : Yes
  • Application Visualization : Yes
Networking:
  • IP address assignment :  Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
  • NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
  • Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing, multicast
  • QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
  • Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
  • Local user database : 150
  • VoIP : Full H.323v1-5, SIP
  • Standards  : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
  • Certifications : VPNC, IPv6 (Phase 2)
  • Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
  • Common Access Card (CAC) : Supported
  • High Availability : Active/Standby with stateful synchronization
Hardware:
  • Form factor : Desktop
  • Power Supply (W) : 36W external
  • Maximum power consumption (W) : 13.4 / 17.7
  • Input power : 100 to 240 VAC, 50-60 Hz, 1 A
  • Total heat dissipation : 45.9 / 60.5 BTU
  • Dimensions : 3.5x15x22.5cm
  • Weight : 0.92 Kg / 2.03 lbs & 1.05 Kg / 2.31 lbs
  • WEEE weight : 1.34 Kg / 2.95 lbs & 1.48 Kg / 3.26 lbs
  • Shipping weight : 1.93 Kg / 4.25 lbs & 2.07 Kg / 4.56 lbs
  • MTBF (Years) : 20 / 12
  • Environment : 40-105° F, 0-40° C
  • Humidity : 5-95% non-condensing
