Latest interactive panel Models Hyderabad, Telangana
Interactive Panel
Pricelist of Best interactive panel Models
- Brand: Benq
- Product: Benq RP7502 75 Inch Interactive Display
- Screen size: 98 inch
- Panel type: IPS
- Active area: 2158.85 × 1214.35 mm
- Aspect ratio: 16:9
- Resolution: UHD 3840 × 2160 pixels
- Response time: 8 ms
- Color depth: 10-bit
- Orientation: Landscape
- Operation hours: 18 hours / 7 days
- Panel brightness (typical): 450 nits
- Contrast ratio (typical): 1200:1
- Dynamic contrast ratio: 30,000:1
- Color gamut: 72% NTSC
- Backlight life (typical): 50,000 hrs
- Memory|Storage: 4GB I 32GB
- OS: Android 8.0
- GPU: Mali-G51MP4
- CPU: A73 × 2 + A53 × 2
- VGA: 1|0
- HDMI (in | out): 3 × HDMI 2.0 | 1 × HDMI 2.0
- DisplayPort: 1 × 1.2 | No
- USB-A: 3 × 2.0 + 2 × 3.0
- USB-C: 1 × 3.0
- USB-B (for touch): 2 × 2.0
- 3.5 mm Line in (1): PC Audio × 1
- 3.5 mm Line out: Earphone × 1
- OPS slot (for slot-in PC): 1
- S/PDIF out: 0 | 1 (optical)
- Ethernet: 10 / 100 Mbps (Android), 10 / 100 Mbps (OPS) × 2
- RS-232: 1 | 0
- NFC sensor: Yes
- Motion sensor: 3
- Microphone: 8 (Max. pickup range 8m)
- Speaker: 2 × 16 W
- Air sensor: TVOC
- Subwoofer: 1 × 15 W
- Cables: 1 × VGA (3 m|9.8 ft), 1 × HDMI (3 m|9.8 ft), 1 × USB-B for touch (3 m|9.8 ft), 1 × USB-C (1.5 m|4.9 ft)
- Brand: Benq
- Product: Benq RE8601 86 Inch Interactive Touchscreen
- Screen size: 86 inch
- Panel type: IPS
- Active area: 1895.0 × 1066.0 mm
- Aspect ratio: 16:9
- Resolution: UHD 3840 × 2160 pixels
- Response time: 8 ms
- Color depth: 10-bit
- Orientation: Landscape
- Operation hours: 18 hours / 7 days
- Panel brightness (typical): 500 nits
- Contrast ratio (typical): 1200:1
- Dynamic contrast ratio: 30,000:1
- Color gamut: 68% NTSC
- Backlight life (typical): 50,000 hrs
- Memory | Storage: 3GB I 32GB
- OS: Android 8.0
- GPU: Mali-G51MP2
- CPU: A73 × 2 + A53 × 2
- VGA: 1 | 0
- HDMI (in | out): 3 × HDMI 2.0 | 1 × HDMI 2.0
- DisplayPort: 1 × 1.2 | No
- USB-A: 2 × 2.0 + 2 × 3.0 for OPS
- USB-B (for touch): 2 × 2.0
- 3.5 mm Line in (1): PC Audio × 1
- 3.5 mm Line out: Earphone × 1
- OPS slot (for slot-in PC): 1
- S/PDIF out: 0 | 1 (optical)
- Ethernet: 10 / 100 Mbps (Android), 10 / 100 Mbps (OPS) × 2
- RS-232: 1 | 0
- Speaker: 2 × 15 W
- Cables: 1 × VGA (3 m|9.8 ft), 1 × HDMI (3 m|9.8 ft), 1 × USB-B for touch (3 m|9.8 ft)
- Brand: Benq
- Product: Benq RE9801 98 Inch Interactive Smart Board
- Screen size: 98 inch
- Panel type: IPS
- Active area: 2158.85 × 1214.35 mm
- Aspect ratio: 16:9
- Resolution: UHD 3840 × 2160 pixels
- Response time: 8 ms
- Color depth: 10-bit
- Orientation: Landscape
- Operation hours: 18 hours / 7 days
- Panel brightness (typical): 500 nits
- Contrast ratio (typical): 1200:1
- Dynamic contrast ratio: 30,000:1
- Color gamut: 68% NTSC
- Backlight life (typical): 50,000 hrs
- Memory | Storage: 3GB I 32GB
- OS: Android 8.0
- GPU: Mali-G51MP2
- CPU: A73 × 2 + A53 × 2
- VGA: 1 | 0
- HDMI (in | out): 3 × HDMI 2.0 | 1 × HDMI 2.0
- DisplayPort: 1 × 1.2 | No
- USB-A: 2 × 2.0 + 2 × 3.0 for OPS
- USB-B (for touch): 2 × 2.0
- 3.5 mm Line in (1): PC Audio × 1
- 3.5 mm Line out: Earphone × 1
- OPS slot (for slot-in PC): 1
- S/PDIF out: 0 | 1 (optical)
- Ethernet: 10 / 100 Mbps (Android), 10 / 100 Mbps (OPS) × 2
- RS-232: 1 | 0
- Speaker: 2 × 15 W
- Cables: 1 × VGA (3 m|9.8 ft), 1 × HDMI (3 m|9.8 ft), 1 × USB-B for touch (3 m|9.8 ft)
- Brand: Benq
- Product: Benq RE7501 Pro 75 Inch Interactive Display
- Screen size: 75 inch
- Panel type: IPS
- Active area: 1649.7 × 927.9 mm
- Aspect ratio: 16:9
- Resolution: UHD 3840 × 2160 pixels
- Response time: 8 ms
- Color depth: 10-bit
- Orientation: Landscape
- Operation hours: 18 hours / 7 days
- Panel brightness (typical): 550 nits
- Contrast ratio (typical): 1200:1
- Dynamic contrast ratio: 30,000:1
- Color gamut: 72% NTSC
- Backlight life (typical): 50,000 hrs
- Memory | Storage: 3GB I 32GB
- OS: Android 8.0
- GPU: Mali-G51MP2
- CPU: A73 × 2 + A53 × 2
- VGA: 1 | 0
- HDMI (in | out): 3 × HDMI 2.0 | 1 × HDMI 2.0
- DisplayPort: 1 × 1.2 | No
- USB-A: 2 × 2.0 + 2 × 3.0 for OPS
- USB-B (for touch): 2 × 2.0
- 3.5 mm Line in (1): PC Audio × 1
- 3.5 mm Line out: Earphone × 1
- OPS slot (for slot-in PC): 1
- S/PDIF out: 0 | 1 (optical)
- Ethernet: 10 / 100 Mbps (Android) × 2
- RS-232: 1 | 0
- Speaker: 2 × 15 W
- Cables: 1 × VGA (3 m|9.8 ft), 1 × HDMI (3 m|9.8 ft), 1 × USB-B for touch (3 m|9.8 ft)
- Brand: Benq
- Product: Benq RE7503 Pro 75 Inch Interactive Display
- Screen size: 75 inch
- Panel type: IPS
- Active area: 67.3 * 40.2 *3.5 Inch
- Aspect ratio: 16:9
- Resolution: UHD 3840 * 2160 pixels
- Response time: 8 ms
- Color depth: 10-bit
- Orientation: Landscape
- Operation hours: 18 hours / 7 days
- Panel brightness (typical): 400 nits
- Contrast ratio (typical): 1200:1
- Dynamic contrast ratio: 30,000:1
- Color gamut: 72% NTSC
- Backlight life (typical): 50,000 hrs
- Memory | Storage: 8 GB | 64 GB (depends on region)
- OS: Android 11.0
- GPU: G52 MP8
- CPU: A73 × 4 + A53 × 4
- VGA: 1
- HDMI (in | out): 3 × HDMI 2.0 | 1 × HDMI 2.0
- DisplayPort: 1 × 1.2a
- USB-A: 2 × 2.0 + 5 × 3.0
- USB-C: 1 × 3.0 + 1 × 3.0 (PD 65 W)
- USB-B (for touch): 3 × 3.0
- 3.5 mm Line in (1): PC Audio × 1
- 3.5 mm Line out: Earphone × 1
- OPS slot (for slot-in PC): 1
- Micro SD reader: ×1 (Expandable up to 512GB)
- S/PDIF out: 0 | 1 (optical)
- Ethernet: 10 / 100 / 1000 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 2
- 3.5 mm Line in (2): PC Audio × 1
- RS-232: 1
- NFC sensor: Yes
- Ambient light sensor: Yes
- IR sensor: Yes
- Microphone: 8-microphone array (range: up to 8 m | 26ft)
- Speaker: 2 × 16 W
- Air sensor: TVOC
- Subwoofer: 1 × 16 W
- Air Ionizer: Yes
- Cables: 1 × VGA (3 m|9.8 ft), 1 × HDMI (3 m|9.8 ft), 1 × USB-B for touch (3 m|9.8 ft), 1 × USB-C (1.5 m|4.9 ft)
- Brand: Benq
- Product: Benq RP6503 Pro 65 Inch Interactive Display
- Screen size: 65 inch
- Panel type: IPS
- Active area: 1428.5 × 803.5 mm
- Aspect ratio: 16:9
- Resolution: UHD 3840 × 2160 pixels
- Response time: 8 ms
- Color depth: 10-bit
- Orientation: Landscape
- Operation hours: 18 hours / 7 days
- Panel brightness (typical): 400 nits
- Contrast ratio (typical): 1200:1
- Dynamic contrast ratio: 30,000:1
- Color gamut: 72% NTSC
- Backlight life (typical): 50,000 hrs
- Memory|Storage: 8 GB | 64 GB (depends on region)
- OS: Android 11.0
- GPU: G52 MP8
- CPU: A73 × 4 + A53 × 4
- VGA: 1
- HDMI (in | out): 3 × HDMI 2.0 | 1 × HDMI 2.0
- DisplayPort: 1 × 1.2a
- USB-A: 2 × 2.0 + 5 × 3.0
- USB-C: 1 × 3.0 + 1 × 3.0 (PD 65 W)
- USB-B (for touch): 3 × 3.0
- 3.5 mm Line in (1): PC Audio × 1
- 3.5 mm Line out: Earphone × 1
- OPS slot (for slot-in PC): 1
- Micro SD reader: ×1 (Expandable up to 512GB)
- S/PDIF out: 0 | 1 (optical)
- Ethernet: 10 / 100 / 1000 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 2
- 3.5 mm Line in (2): PC Audio × 1
- RS-232: 1
- NFC sensor: Yes
- Ambient light sensor: Yes
- IR sensor: Yes
- Microphone: 8-microphone array (range: up to 8 m | 26ft)
- Speaker: 2 × 16 W
- Air sensor: TVOC
- Subwoofer: 1 × 16 W
- Air Ionizer: Yes
- Cables: 1 × VGA (3 m|9.8 ft), 1 × HDMI (3 m|9.8 ft), 1 × USB-B for touch (3 m|9.8 ft), 1 × USB-C (1.5 m|4.9 ft)
- Brand: Benq
- Product: Benq RP8603 Pro 86 Inch Interactive Display
- Screen size: 86 inch
- Panel type: IPS
- Active area: 1895.0 × 1066.0 mm
- Aspect ratio: 16:9
- Resolution: UHD 3840 × 2160 pixels
- Response time: 8 ms
- Color depth: 10-bit
- Orientation: Landscape
- Operation hours: 18 hours / 7 days
- Panel brightness (typical): 450 nits
- Contrast ratio (typical): 1200:1
- Dynamic contrast ratio: 30,000:1
- Color gamut: 72% NTSC
- Backlight life (typical): 50,000 hrs
- Memory | Storage: 8 GB | 64 GB (depends on region)
- OS: Android 11.0
- GPU: G52 MP8
- CPU: A73 × 4 + A53 × 4
- VGA: 1
- HDMI (in|out): 3 × HDMI 2.0 | 1 × HDMI 2.0
- DisplayPort: 1 × 1.2a
- USB-A: 2 × 2.0 + 5 × 3.0
- USB-C: 1 × 3.0 + 1 × 3.0 (PD 65 W)
- USB-B (for touch): 3 × 3.0
- 3.5 mm Line in (1): PC Audio × 1
- 3.5 mm Line out: Earphone × 1
- OPS slot (for slot-in PC): 1
- Micro SD reader: ×1 (Expandable up to 512GB)
- S/PDIF out: 0 | 1 (optical)
- Ethernet: 10 / 100 / 1000 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 2
- 3.5 mm Line in (2): PC Audio × 1
- RS-232: 1
- NFC sensor: Yes
- Ambient light sensor: Yes
- IR sensor: Yes
- Microphone: 8-microphone array (range: up to 8 m | 26ft)
- Speaker: 2 × 16 W
- Air sensor: TVOC
- Subwoofer: 1 × 16 W
- Air Ionizer: Yes
- Cables: 1 × VGA (3 m|9.8 ft), 1 × HDMI (3 m|9.8 ft), 1 × USB-B for touch (3 m|9.8 ft), 1 × USB-C (1.5 m|4.9 ft)
- Brand: Benq
- Product: Benq RP7503 Pro 75 Inch Interactive Display
- Screen size: 75 inch
- Panel type:IPS
- Active area: 1649.7 × 927.9 mm
- Aspect ratio: 16:9
- Resolution: UHD 3840 × 2160 pixels
- Response time: 8 ms
- Color depth: 10-bit
- Orientation: Landscape
- Operation hours: 18 hours / 7 days
- Panel brightness (typical): 450 nits
- Contrast ratio (typical): 1200:1
- Dynamic contrast ratio: 50,000:1
- Color gamut: 72% NTSC
- Backlight life (typical): 30,000 hrs
- Memory | Storage: 8 GB | 64 GB (depends on region)
- OS: Android 11.0
- GPU: G52 MP8
- CPU: A73 × 4 + A53 × 4
- VGA: 1
- HDMI (in | out): 3 × HDMI 2.0 | 1 × HDMI 2.0
- DisplayPort: 1 × 1.2a
- USB-A: 2 × 2.0 + 5 × 3.0
- USB-C: 1 × 3.0 + 1 × 3.0 (PD 65 W)
- USB-B (for touch): 3 × 3.0
- 3.5 mm Line in (1): PC Audio × 1
- 3.5 mm Line out: Earphone × 1
- OPS slot (for slot-in PC): 1
- Micro SD reader: ×1 (Expandable up to 512GB)
- S/PDIF out: 0 | 1 (optical)
- Ethernet: 10 / 100 / 1000 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 2
- 3.5 mm Line in (2): PC Audio × 1
- RS-232: 1
- NFC sensor: Yes
- Ambient light sensor: Yes
- IR sensor: Yes
- Microphone: 8-microphone array (range: up to 8 m | 26ft)
- Speaker: 2 × 16 W
- Air sensor: TVOC
- Subwoofer: 1 × 16 W
- Air Ionizer: Yes
- Cables: 1 × VGA (3 m|9.8 ft), 1 × HDMI (3 m|9.8 ft), 1 × USB-B for touch (3 m|9.8 ft), 1 × USB-C (1.5 m|4.9 ft)
- Brand: Benq
- Product: Benq RP04 75 Inch Interactive Flat Display
- Screen size: 75 inch
- Panel type :IPS
- Active area: 1649.7 × 927.9 mm
- Aspect ratio: 16:9
- Resolution: UHD 3840 × 2160 pixels
- Response time: 8 ms
- Color depth: 10-bit
- Orientation: Landscape
- Operation hours: 18 hours / 7 days
- Panel brightness (typical): 450 nits
- Contrast ratio (typical): 1200:1
- Dynamic contrast ratio: 50,000:1
- Color gamut: 72% NTSC
- Backlight life (typical): 50,000 hrs
- Memory | Storage: 8 GB | 128 GB (depends on region)
- OS: Android 15.0
- GPU: Arm Mali-G57 MC5
- CPU: Arm Cortex-A78 × 4 + A55 × 4
- VGA: 1
- HDMI (in | out): 4 × HDMI 2.0 | 1 × HDMI 2.0
- DisplayPort: 1 × 1.2a
- USB-A: 7 × 3.0, 1 × 2.0
- USB-C: 1 × 3.0 (PD 100 W), 2 × 3.0, 1 × 2.0 (PD 65 W)
- USB-B (for touch): 3 × 3.0
- 3.5 mm Line in (1): PC Audio × 1
- 3.5 mm Line out: Earphone × 1
- OPS slot (for slot-in PC): 1
- Micro SD reader: ×1 (Expandable up to 512GB)
- S/PDIF out: 0 | 1 (optical)
- Ethernet: 10 / 100 / 1000 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 2
- 3.5 mm Line in (2): Mic × 1
- RS-232: 1
- NFC sensor: Yes
- Ambient light sensor: Yes
- IR sensor: Yes
- Microphone: 8-microphone array (range: up to 8 m | 26ft)
- Speaker: 2 × 20 W (max)
- Camera: 1
- Cables: 1 × VGA (3 m|9.8 ft), 1 × HDMI (3 m|9.8 ft), 1 × USB-B for touch (3 m|9.8 ft), 1 × USB-C (1.5 m|4.9 ft)
- Brand: Benq
- Product: Benq RE9804FV 98 Inch Interactive Display
- Screen size :98 inch
- Panel type :IPS
- Active area: 1895.0 × 1096.0 mm
- Aspect ratio: 16:9
- Resolution: UHD 3840 × 2160 pixels
- Response time: 8 ms
- Color depth: 10-bit
- Orientation: Landscape
- Operation hours: 18 hours / 7 days
- Panel brightness (typical): 500 nits
- Contrast ratio (typical): 1200:1
- Dynamic contrast ratio: 30,000:1
- Color gamut: 68% NTSC
- Backlight life (typical): 50,000 hrs
- Memory | Storage: 8 GB | 128 GB (depends on region)
- OS: Android 13 (EDLA)
- GPU: G52 MP8
- CPU: A73 × 4 + A53 × 4
- VGA: 1
- HDMI (in | out): 3 × HDMI 2.0 | 1 × HDMI 2.0
- DisplayPort: 1 × 1.2a
- USB-A: 2 × 2.0 + 2 × 3.0
- USB-C: 1 × 2.0 + 1 × 3.0 (PD 65 W)
- USB-B (for touch): 2 × 2.0
- 3.5 mm Line in (1): PC Audio × 1
- 3.5 mm Line out: Earphone × 1
- OPS slot (for slot-in PC): 1
- Micro SD reader: ×1 (Expandable up to 512GB)
- S/PDIF out: 0 | 1 (optical)
- Ethernet: 10 / 100 / 1000 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 2
- 3.5 mm Line in (2): Mic × 1
- RS-232: 1
- NFC sensor: Yes
- Ambient light sensor: Yes
- IR sensor: Yes
- Microphone: 8-microphone array (range: up to 8 m | 26ft)
- Speaker: 2 × 20 W (max)
- Camera: 1
- Cables: 1 × VGA (3 m|9.8 ft), 1 × HDMI (3 m|9.8 ft), 1 × USB-B for touch (3 m|9.8 ft), 1 × USB-C (1.5 m|4.9 ft)
- Brand: Raptor
- Product: RPDCI86 86 inch Interactive Panel
- Model No: RPDCI86
- Display Size: 86 inch
- Bonding Technology: In-Plane Switching (IPS)
- Response Time: 8ms
- Display Type: Anti-Glare LCD with Direct-lit LED
- Aspect Ratio: 16:9
- Max Visual Area (H/V) (mm): 1896×1067
- Resolution (H/V): 4K UHD 3840×2160
- Pixel Pitch (mm): 0.4935×0.4935
- Refresh Rate: 60Hz or 120Hz
- Display Color: 1.07B (10bit)
- Color Gamut NTSC(Typ.): 72%
- Contrast Ratio(Typ): 1200:1/4000:1
- Viewing Angles (H/V): 178:178
- Back Light Unit: DLED
- Brightness: 350 cd/m2 (98”400 cd/m2)
- Panel Life: ?30000 hours
- System Version: Android 14.0
- Solution: V100
- Frequency: 1.2GHZ
- CPU: 8 Core A55 GPU Octa-core Mali G52 MP4
- RAM: 8GB
- ROM: 128GB
- Touch Technology: Infrared Touch
- Supporting Systems: Windows10/8/7/XP/Android/Linux/Mac OS X/Chrome
- Touch Point: 40 Points Touch
- Min. Object Size: 2mm
- Interactivity: Simultaneous Pen and Touch
- Touch Feature: Annotation, Painting, Eraser, Highlighter, PDF Viewer, PPT Viewer, Browser, Movies & Image Viewer, External Source annotation
- Brand: LG
- Model No: 55TR3DK
- Product: LG 55TR3DK Interactive Panel Display
- Size: 55 Inch 3,840 × 2,160 (UHD)
- Panel Technology: IPS Panel
- Brightness: 440 nit
- Input Type: Pen Based
- Multi-Touch Point: Max. 40 Points
- Input Port: HDMI (3, HDCP2.2), RGB (1, VGA),Audio (1), RS-232C (1), RJ45(1, LAN),USB3.0 Type A (4), USB2.0 Type A (1),USB Type-C (1, USB-PD, DP-Alt)
- OutputPort: HDMI (1), Audio Out (1, Optical 1(SPDIF)), Touch USB (2), RJ45(1, LAN)
- Power Consumption: 150 - 220 W
- Usage/Application: Office
- Effective Touch Area: 47 x 26
- Color: White
- Brand: LG
- Part No: 43UM5N
- Product: 43UM5N 43inch interactive Display
- Display Size: 43-inch Full HD Commercial Display offering crisp
- Resolution1920 x 1080 resolution
- Multiple connectivity options: including HDMI, USB, and RS232C
- Designed: versatile professional use in retail, hospitality, corporate, and educational environments. This display combines reliable performance with easy-to-use smart features to deliver impactful digital signage and presentations.
- Brand: LG
- Product: LG 43UH5JH 43 New High Haze UHD Standard Signage
- Screen Size: 43
- Panel Technology: IPS
- Back Light Type: Edge
- Aspect Ratio: 16 : 9
- Native Resolution: 3840 x 2160 (UHD)
- Refresh Rate: 60Hz
- Brightness: 500nit (Typ.)
- Contrast Ratio: 1,200:1
- Dynamic CR: 1,000,000:1
- Color gamut: BT709 95%
- Viewing Angle(H x V): 178 X 178
- Color Depth: 8bits + FRC, 1.07Billion colors
- Response Time: 8ms (G to G)
- Surface Treatment(Haze): 25%
- Life time: 50,000Hrs (Min.)
- Operation Hours (Hours/Day): 24/7
- Portrait / Landscape: Yes / Yes
- Connectivity Input: HDMI (3, HDMI1/HDMI2 : HDCP 2.2/1.4, HDMI3 : HDCP 1.4), DP (1, HDCP2.2/1.3), DVI-D (HDCP1.4), Audio In, RS232C IN (1, 4pin Phone-jack), RJ45(LAN), IR IN, USB2.0 Type A(1)
- Connectivity Output: HDMI Out, Audio Out, RS232C OUT (1, 4pin Phone-jack)
- Monitor Dimensions (W x H x D): 962.5 x 613.1 x 290.0mm
- Weight(Head+Stand): 11.8Kg
- Brand: OPS
- Model No: OPS 98 Inch Interactive Flat Panel
- Mounting: Wall Mount
- Panel back light: TFT-LCD Module
- Type of CPU: Intel core i5
- Operating System: Window 11 pro trail os
- Memory Capacity: 8GB RAM
- Storage Capacity: 256GB SSD
- Display Size: 98 Inches 4K UHD 3840 x 2160
- Display Type: Anti-Glare LCD with Direct-lit LED
- Minimum Contrast Ratio: 1400 : 1
- Minimum Display Panel Size, Diagonal (in Inches): 98
- Display Brightness (in Nits): 400
- Minimum Panel Life (in Hours): 50000
- Touch Interface: Touch Sensitive as well as Pen Driven
- Touch Technology: Infrared (IR)
- Number of Touch Points (in Number): 40
- Additional Softwares: Device Management Software
- Provision of Slot for Open pluggable Specification (OPS): Yes
- Open pluggable Specification (OPS) included in scope of supply: Yes
- Pre-Install Software (OS) for Open pluggable Specification (OPS): Windows
- Port: 3 X Input HDMI Ports; 1 X Output HDMI Ports
- In-built Speakers: Yes
- Brand: OPS
- Model No: OPS 110 Inch Interactive Flat Panel
- Mounting: Wall Mount
- Panel back light: TFT-LCD Module
- Type of CPU: Intel core i5
- Operating System: Window 11 pro trail os
- Memory Capacity: 8GB RAM
- Storage Capacity: 256GB SSD
- Display Size: 110 Inches 4K UHD - 3840 x 2160
- Display Technology: In-Plane Switching (IPS)
- Display Type: Anti-Glare LCD with Direct-lit LED
- Minimum Contrast Ratio: 1400 : 1
- Display Brightness (in Nits): 400
- Display Aspect Ratio: 16:09
- View Angle (in Degree): 178 /178
- Minimum Panel Life (in Hours): 50000
- Touch Interface: Touch Sensitive as well as Pen Driven
- Touch Technology: Infrared (IR)
- Port: 3 X Number of Input HDMI Ports; 1 X Number of Output HDMI Ports; 2 X Number of USB 2 Point 0 Ports; 1 X Number of USB 3 Point 0 Ports; 1 x USB Type C Port
- Availability of Bluetooth Connectivity: Yes. Inbuilt
- Bluetooth Version: 5.3
- Availibility of WiFi Connectivity: Yes. Inbuilt
- WiFi Connectivity: 802.11n (2.4 or 5 GHz)
- Brand: Raptor
- Model No: Raptor 98 Inch Interactive Flat Panel
- Mounting: Wall Mount
- Type of CPU: Inbuilt CPU with Slot Provision for Open pluggable Specification (OPS)
- Number of Cores: 8
- Memory Capacity: 4GB RAM
- Storage Capacity: 128 ROM
- Display Size: 98 Inches 4K UHD 3840 x 2160
- Display Type: Anti-Glare LCD with Direct-lit LED
- Minimum Contrast Ratio: 1400 : 1
- Minimum Display Panel Size, Diagonal(in Inches): 98
- Display Brightness(in Nits): 400
- Minimum Panel Life(in Hours): 50000
- Touch Interface: Touch Sensitive as well as Pen Driven
- Touch Technology: Infrared (IR)
- Number of Touch Points (in Number): 40
- Additional Softwares: Device Management Software
- Provision of Slot for Open pluggable Specification (OPS): Yes
- Open pluggable Specification (OPS) included in scope of supply: Yes
- Pre-Install Software (OS) for Open pluggable Specification (OPS): Windows
- Port: 3 X Input HDMI Ports; 1 X Output HDMI Ports
- In-built Speakers: Yes
- Availability of Bluetooth Connectivity: Yes. Inbuilt
- Bluetooth Version: 5.3
- Availibility of Wi-Fi Connectivity: Yes. Inbuilt
- WiFi Connectivity: 802.11n (2.4 or 5 GHz)
- Kit: User Manual, HDMI cable, Installation Manual, Remote Control with battery, Power Cord, USB Cable
- Warranty: 3 years Warranty
- Brand: Raptor
- Model No: Raptor 110 Inch Interactive Flat Panel
- Mounting: Wall Mount
- Type of CPU: Inbuilt CPU with Slot Provision for Open pluggable Specification (OPS)
- Number of Cores: 8
- Memory Capacity: 4GB RAM
- Storage Capacity: 128 ROM
- Pre-Install Software (OS): Android
- Display Size: 110 Inches 4K UHD-3840 x 2160
- Display Technology: In-Plane Switching (IPS)
- Display Type: Anti-Glare LCD with Direct-lit LED
- Minimum Contrast Ratio: 1400:1
- Display Brightness(in Nits): 400
- Display Aspect Ratio: 16:10
- View Angle (in Degree): 178 /178
- Minimum Panel Life (in Hours): 50000
- Touch Interface: Touch Sensitive as well as Pen Driven
- Touch Technology: Infrared (IR)
- Port: 3 X Number of Input HDMI Ports; 1 X Number of Output HDMI Ports; 2 X Number of USB 2 Point 0 Ports; 1 X Number of USB 3 Point 0 Ports; 1 x USB Type C Port
- Availability of Bluetooth Connectivity: Yes. Inbuilt
- Bluetooth Version: 5.3
- Availibility of WiFi Connectivity: Yes. Inbuilt
- WiFi Connectivity: 802.11n (2.4 or 5 GHz)
- Kit: User Manual, HDMI cable, Installation Manual, Remote Control with battery, Power Cord, USB Cable
- Warranty: 3 years Warranty
- Brand: Raptor
- Model No: Raptor 65 Inch Interactive Flat Panel
- Display Size: 65 inch 4k Ultra HD screen
- Display Type: LED
- RAM: 4GB RAM
- Resolution(H X V): 3840 X 2160
- Display Colour: 1.07 Billion Colours
- Pixle Pitch :0.372mmX0.372 mm/0.430 MM *0.430mm
- Speaker Output: 15W x 2
- Touch Resolution: 32768 X 32768
- Touch Accuracy: 1 Mm
- Warranty: 1 year warranty
- Brand: Raptor
- Part Number: KTI120060RAIFP75
- Model No: Raptor 75 Inch Interactive Flat Panel
- Display Size: 75 inch Android 12Ultra HD Display
- Display Type: LED
- RAM: 4GB RAM
- Resolution(H X V): 3840X2160
- Display Colour: 1.07 Billion Colours
- Pixle Pitch :0.372mmX0.372 mm/0.430 MM *0.430mm
- Speaker Output: 20W X2
- Touch Resolution: 32768X32768
- Touch Accuracy: 1 Mm
- Warranty: 1 year Warranty
- Brand: Optoma
- Model No: Optoma FHDQ163 All In One QUAD LED Display
- Screen resolution: 1080p Full HD (1920x1080)
- Screen size (diagonal): 163 inch
- Screen size: 360 x 202.5
- Minimum viewing distance: 1.9m
- Brightness (before calibration): 600 nits
- Brightness (after calibration): 600 nits
- Contrast: 5000:1
- Pixel pitch (H x V): 1.875mm
- LEDs per pixel: 3
- Pixel configuration: Quad LED
- LED face colour: Black
- Pixel resolution (width): 128 pixels/module
- Pixel resolution (height): 72 pixels/module
- Pixels per area: 2,84,444 pixels/m2
- Connections: Inputs 1 x RS232, 2 x HDMI, 1 x 3G-SDI, 1 x USB-A, 2 x USB-A service, 1 x USB-B service, Outputs 1 x RS232, 1 x Audio 3.5mm, 1 x HDMI, Control 1 x HDBaseT, 1 x RJ45
- Active module width: 3603.3
- Active module height: 2028.4
- Standard active module area: 7.29m2
- Number of colours: 281 (trillions)
- Refresh rate: 3,840 Hz
- Brightness (before calibration): 600nits
- Brightness (after calibration): 600nits
- Contrast ratio: 5,000
- Brightness control levels: 100
- Input power (max): 3,000watts per panel
- Dimensions (W x D x H): 3603.3 x 79 x 2028.4
- Weight: 191 kg
- Brand: Optoma
- Model No: Optoma FHDS130 All In One LED Display
- Screen resolution: 1080p Full HD (1920x1080)
- Screen size (diagonal): 130 inch
- Screen size: 291.9 x 165.9
- Minimum viewing distance: 1.5m
- Brightness (before calibration): 800 nits
- Contrast: 5000:1
- Pixel pitch (H x V): 1.5mm
- LEDs per pixel: 3
- Pixel configuration: SMD 3-1
- LED face colour: Black
- LED size: SMD1010
- Connections: Inputs 2 x HDMI 2.0, 1 x 3G-SDI, 1 x VGA, 1 x RJ45, 1 x RS232, 1 x USB-B service, 2 x USB-A, 1 x USB-A service, 1 x HDBaseT, Outputs 1 x Audio 3.5mm
- Pixel resolution (width): 160 pixels/module
- Pixel resolution (height): 90 pixels/module
- Pixels per area: 4,44,444 pixels/m2
- Active module width: 2,919
- Active module height: 1,659
- Standard active module area: 4.82m2
- Greyscale processing depth: 16 bits
- Number of colours: 281 (trillions)
- Refresh rate: >3000 Hz
- Contrast ratio: 5,000
- Brightness control levels: 100
- Input power (max): 3,000watts per panel
- Power supply: 200 - 240V
- Dimensions (W x D x H): 2919 x 71 x 1659
- Weight: 125 kg
- Brand: Optoma
- Model No: Optoma 3862RK Touch 3 Series Interactive Display
- Back light: Direct type LED
- Size (diagonal): 86 inch
- Resolution: 3840 x 2160 (UHD 4K)
- Brightness: 400
- Contrast ratio: 4,000:1
- Viewing angle: 178°
- Response time: 8ms
- Life: 50,000 hours
- Speaker count: 2
- Watts per speaker: 20W
- System version: Android 13.0
- CPU: Quad-core
- GPU: Dual-core
- RAM: 4GB
- Storage: 32GB
- Glass: 4 mm Tempered Glass with Anti Glare + Anti Fingerprint
- Ambient light sensor: Yes
- Connections: Inputs 3 x HDMI 2.0, 1 x VGA, 1 x Audio 3.5mm, 1 x S/PDIF, 3 x USB 2.0, 2 x USB 3.0, 1 x USB-C, 1 x RJ45, 1 x DisplayPort, 1 x Mic 3.5mm, Outputs 1 x HDMI 2.0, 1 x Audio 3.5mm, 1 x RJ45, Control 2 x USB Touchport, 1 x RS232
- Weight: 81 kg
- System: Windows10/Windows11/Linux/Mac (1 Touch point only)/Android/Chrome
- Touch accuracy: <1.50mm
- Touch point: Up to 20 points touch
- Touch tool: Finger, Passive infrared pen
- Pen/finger detection: Yes
- Power supply: AC 100-240V, 50/60 Hz
- Power consumption (standby): 0.5W
- Power consumption (max): 450W
- Dimensions (W x D x H): 1981 x 1187 x 117
- Weight: 81 kg
- Brand: Optoma
- Model No: Optoma 5862RK Touch 5 Series Interactive Display
- Back-light: Direct Type LED
- Size (diagonal): 86 inch
- Resolution: 4K UHD (3840 × 2160)
- Brightness: 420 cd/m2
- contrast ratio: 1,200:1
- Contrast ratio (dynamic): 4,000:1
- viewing angle: 178°
- Response time: 6ms
- Life: 50,000 hours
- Speaker count: 2
- Watts per speaker: 20W
- System Version: Android 9.0
- CPU: 4G Quad Core A73
- GPU: Mali-G52
- RAM: 4GB
- Storage: 32GB
- Glass: Toughened, Anti-glare/Fingerprint
- Air gap: 0.80mm
- Touch resolution: 32768 x 32768
- Connections: Inputs 3 x HDMI, 1 x VGA, 1 x Audio 3.5mm, 1 x S/PDIF, 4 x USB 3.0, 1 x USB 2.0, 2 x RJ45, 1 x USB-C, 2 x USB Touchport, Outputs 1 x HDMI, 1 x Audio 3.5mm, 1 x RS232 Controller
- System: Windows10/Windows8/Windows7/Windows XP /Linux/Mac (1 Touch point only)/Android/Chrome
- Touch Point: Up to 20 points touch and 40 points touch (Windows)
- TouchTools: Fingerprint, Passive infra-red pen
- Power Supply: 100-240V~ 50/60Hz
- Power consumption (standby): 0.292W
- Power consumption (max): 490W
- Power consumption - average (watts): 162.6
- Dimensions (W x D x H): 1957 x 86 x 1160
- Weight: 83kg
- Brand: Optoma
- Model No: Optoma 5863RK Touch 5 Series Interactive Display
- Back light: Direct type LED
- Size (diagonal): 86 inch
- Resolution: 3840(H)*2160(V) Pixel (4K UHD)
- Brightness: 450 cd/m2
- Contrast ratio: 4,000:1
- Contrast ratio (dynamic): 4,500:1
- Viewing angle: 178°
- Response time: 6ms
- Life: 50,000 hours
- Speaker Info: 18W speakers*2 + 8W subwoofers*2
- Surface hardness: 7H
- Glass: Toughened, Anti-glare/Fingerprint / HAZE: 3-8%
- Air gap: 0.60mm
- Pencil hardness: 9H
- System version: Android 13
- CPU: Octa-core (A76*4 + A55*4)
- GPU: Mali G610 MC4
- RAM: 8GB
- Storage: 64GB
- Touch resolution: 32768 x 32768
- Connections: Inputs 4 x HDMI 2.0, 1 x DisplayPort, 1 x Audio 3.5mm, 1 x USB-A service, 4 x USB-A 3.0, 1 x RS232, 1 x RJ45, 2 x USB-C, 1 x OPS slot, Outputs 1 x HDMI 2.0, 1 x S/PDIF, 1 x Audio 3.5mm, 2 x USB Touchport, 1 x RJ45
- System: Windows 11/Windows10/Windows8/Windows7/Windows XP /Linux/Mac (1 Touch point only)/Android/Chrome
- Touch accuracy: 1.00mm
- Touch point: Up to 50 points touch (32 points touch in Android, 50 points touch in Windows, 10 points writing)
- Touch tool: Finger, Passive infra-red pen
- Power supply: 100-240V~ 50/60Hz
- Power consumption (standby): 0.5W
- Power consumption (max): 560W
- Power consumption - average (watts): 370
- Power consumption - Energy Star (watts): 152
- Dimensions (W x D x H): 1957 x 86 x 1171
- Weight: 80 kg
LG 'IR Spread' based
Windows XP (1Point) / Windows 7 (10 Point)
Protection Glass
Anti-Glare
IWB S/W
PANEL
Screen Size 165.10cm (65) Resolution 3,840 x 2,160 (UHD)
Brightness 350nits Back Light Type Direct
CONNECTIVITY - INPUT
HDMI Yes (3) DP No
DVI-D No Analog (RGB) Yes (1)
Analog (Component) No External Control (RS232C IN) Yes (1)
Audio Yes (1) External Control (LAN) Yes (1)
External Control (IR/Light sensor) X (Internal) External Control (Pixel Sensor) No
External Control (Pentray Control) Yes (1) USB USB 3.0 O(3) USB 2.0 O(3) (Front : 2ea, Bottom side *1 Only for software update),
Touch Out (USB 2.0, B Type) O(2)
CONNECTIVITY - OUTPUT
HDMI Yes (1) Audio Out Yes (1)
External Coaxial/Optical Output - O(1) External Control (RS232C OUT) No
POWER
Power Consumption (Typ. / Max.) 145W / 275W
STANDARD(CERTIFICATION)
Safety CB / NRTL ErP / Energy Star Yes(EU Only) / No
MEDIA PLAYER COMPATIBILITY
External Media player Attatchable No
SOFTWARE COMPATIBILITY
SuperSign-w lite No SuperSign-c No
ACCESSORY
Basic Power Cord, Remote Controller (include battery 2ea ), IR/Light sensor receiver, USB 2.0 Cable, HDMI 2.0 Cable, DisplayPort Cable, Cable Tie (2ea),
Touch Pen (2ea), PenTray (1ea), Eye-Bolt Assy (2ea), Screw Package, ESG Optional Media Player: MP700/MP500, External Speaker: SP-2100, Pen Tray: KT-WT1 (TBD)
Brightness: 500 cd/?
Touch Type: P-Cap(Ag Metal Mesh)
Touch Point: Max. 40 points
Interface: HDMI (3), DP, DVI, RGB, RS232C, RJ45, USB (2), OPS USB, Touch USB (2), Wi-Fi Built-in
PANEL
Screen Size 55” Native Resolution 3,840 x 2,160 (UHD)
Brightness (Module, cd/?) 500
CONNECTIVITY
Input HDMI (3), DP, DVI-D, RGB, Audio in, USB 3.0, USB 2.0, OPS USB 2.0 Output Touch USB 2.0 (2)
External Control RS232C in/out, RJ45 in
PHYSICAL SPECIFICATION
Bezel Width 41.6 mm(T/L/R/B) Monitor Dimension (W x H x D) 1,732.8 x 1011.1 x 69.7 mm (w/o Handle)
Weight (Head) 74.5 kg Carton Dimensions (W x H x D) 1,870 x 1,264 x 285 mm(with pallet)
Packed Weight 94 kg VESA™ Standard Mount Interface 600 x 400 mm
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10 % to 80 %
POWER CONSUMPTION
Typ. = 240 W Smart Energy Saving = 170 W
STANDARD(CERTIFICATION)
Safety UL / cUL / CB / TUV / KC EMC FCC Class “A” / CE / KCC
SOFTWARE COMPATIBILITY
Content Management Software SuperSign Premium Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (include battery 2ea), Power Cord, QSG, HDMI (3M), Regulation Book, Phone to RS232C Gender, Touch Pen (2ea),
Touch Pen Tip (1ea) Optional OPS Kit (KT-OPSA), Wall Mount(LSW640A/B)
TOUCH
Touch type P-Cap(Ag Metal Mesh) Available object size for touch more than Ø 6 mm
Accuracy 2 mm Interface USB 2.0
Protection Glass Thickness 4T (Anti-Glare) Multi touch point Max. 40 Points
Brightness: 500 cd/?
Touch Type: P-Cap(Ag Metal Mesh)
Touch Point: Max. 40 points
Interface: HDMI (3), DP, DVI, RGB, RS232C, RJ45, USB (2), OPS USB, Touch USB (2), Wi-Fi Built-in
PANEL
Screen Size 65” Native Resolution 3,840 x 2,160 (UHD)
Brightness (Module, cd/?) 500
CONNECTIVITY
Input HDMI (3), DP, DVI-D, RGB, Audio in, USB 3.0, USB 2.0, OPS USB 2.0 Output Touch USB 2.0 (2)
External Control RS232C in/out, RJ45 in
PHYSICAL SPECIFICATION
Bezel Width 41.6 mm(T/L/R/B) Monitor Dimension (W x H x D) 1,732.8 x 1011.1 x 69.7 mm (w/o Handle)
Weight (Head) 74.5 kg Carton Dimensions (W x H x D) 1,870 x 1,264 x 285 mm(with pallet)
Packed Weight 94 kg VESA™ Standard Mount Interface 600 x 400 mm
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10 % to 80 %
POWER CONSUMPTION
Typ. = 240 W Smart Energy Saving = 170 W
STANDARD(CERTIFICATION)
Safety UL / cUL / CB / TUV / KC EMC FCC Class “A” / CE / KCC
SOFTWARE COMPATIBILITY
Content Management Software SuperSign Premium Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (include battery 2ea), Power Cord, QSG, HDMI (3M), Regulation Book, Phone to RS232C Gender, Touch Pen (2ea), Touch Pen Tip (1ea) Optional OPS Kit (KT-OPSA), Wall Mount(LSW640A/B)
TOUCH
Touch type P-Cap(Ag Metal Mesh) Available object size for touch more than Ø 6 mm
Accuracy 2 mm Interface USB 2.0
Protection Glass Thickness 4T (Anti-Glare) Multi touch point Max. 40 Points
Brightness: 500 cd/?
Touch Type: P-Cap(Ag Metal Mesh)
Touch Point: Max. 40 points
Interface: HDMI (3), DP, DVI, RGB, RS232C, RJ45, USB (2), OPS USB, Touch USB (2), Wi-Fi Built-in
PANEL
Screen Size 75” Native Resolution 3,840 x 2,160 (UHD)
Brightness (Module, cd/?) 500
CONNECTIVITY
Input HDMI (3), DP, DVI-D, RGB, Audio in, USB 3.0, USB 2.0, OPS USB 2.0 Output Touch USB 2.0 (2)
External Control RS232C in/out, RJ45 in
PHYSICAL SPECIFICATION
Bezel Width 41.6 mm(T/L/R/B) Monitor Dimension (W x H x D) 1,732.8 x 1011.1 x 69.7 mm (w/o Handle)
Weight (Head) 74.5 kg Carton Dimensions (W x H x D) 1,870 x 1,264 x 285 mm(with pallet)
Packed Weight 94 kg VESA™ Standard Mount Interface 600 x 400 mm
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10 % to 80 %
POWER CONSUMPTION
Typ. = 240 W Smart Energy Saving = 170 W
STANDARD(CERTIFICATION)
Safety UL / cUL / CB / TUV / KC EMC FCC Class “A” / CE / KCC
SOFTWARE COMPATIBILITY
Content Management Software SuperSign Premium Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (include battery 2ea), Power Cord, QSG, HDMI (3M), Regulation Book, Phone to RS232C Gender, Touch Pen (2ea), Touch Pen Tip (1ea) Optional OPS Kit (KT-OPSA), Wall Mount(LSW640A/B)
TOUCH
Touch type P-Cap(Ag Metal Mesh) Available object size for touch more than Ø 6 mm
Accuracy 2 mm Interface USB 2.0
Protection Glass Thickness 4T (Anti-Glare) Multi touch point Max. 40 Points
Brightness(Typ.): 410 cd/m²
Touch Type: InGlass™
Multi touch point: Max 20 Point
Interface: HDMI (3), DP, DVI, RGB, RS232C, RJ45, USB (2), OPS USB, Touch USB (2), Wi-fi Built-in
PANEL
Screen Size 218.44cm (86) Brightness(Module, Typ., cd/m²) 410
Native Resolution 3840 x 2160 (UHD)
CONNECTIVITY
Input HDMI (3), DP, DVI-D, RGB, Audio, USB 3.0, USB 2.0, OPS USB 2.0 Output Touch USB 2.0 (2)
PHYSICAL SPECIFICATION
Bezel Width 50.7 mm (T/L/R), 62.2 mm (B) Monitor Dimension (W x H x D) 2,026.9 x 1,180.3 x 92.9 mm
Weight (Head) 85.8 kg Carton Dimensions (W x H x D) 2,190 × 1,470 × 371 mm
Packed Weight 114.6 kg VESA™ Standard Mount Interface 600 x 400 mm
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10 % to 80 %
SOFTWARE COMPATIBILITY
Content Management Software SuperSign Premium Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (include battery 2ea), Power Cord, QSG, HDMI (3M), Regulation Book, Phone to RS232C Gender, Touch Pen (2ea), Eyebolt (2ea) Optional
OPS Kit (KT-OPSA)
TOUCH
Touch type InGlass™ Available object size for touch more than Ø 3 mm
Accuracy 2 mm Interface USB 2.0
Protection Glass Thickness 4T (Anti-Glare) Multi touch point Max 20 Point
Floating Tool Bar
SoC and LG webOS
IDB App for Efficient Collaboration
LG FHD Technology
LG IPS Panel with Wide Viewing Angles and True Color
Auto Signal/Touch Switching
PANEL
Screen Size 81.28Cm (32) Panel Technology IPS
Aspect Ratio 16 : 9 Native Resolution 1,920 x 1,080 (FHD)
Brightness (cd/m²) 450 Viewing Angle (HxV) 178 x 178
Response Time 12ms (G to G BW), 9.0ms (WOT) Surface Treatment Hard coating (3H), Anti-glare treatment of the front polarizer, (Haze 1%(Typ.))
Life Time (Typ.) 50,000Hrs Operation Hours 24Hrs
Orientation Landscape & Portrait
CONNECTIVITY
Input HDMI (2), DP, DVI-D, RGB, Audio In, USB 3.0 Output DP, Audio Out
External Control RS232C In/out, RJ45 In, IR Receiver In, Pixer Sensor In
PHYSICAL SPECIFICATION
Bezel Color Black Bezel Width 32.7 mm (Even)
Monitor Dimension (W x H x D) 1,278 x 748.8 x 71.4 mm Weight (Head) 28.0 kg
Carton Dimensions (W x H x D) 1,410 x 880 x 207 mm Packed Weight 33kg
VESA™ Standard Mount Interface 300 x 300 mm
SPECIAL FEATURES
Yes Temperature Sensor, Auto Brightness Sensor, Tile Mode (Up to 15x15), Natural Mode @Tile Mode, ISM Method, DPM Select, Energy Saving,
Smart Energy Saving, File Play with USB, PIP/PBP (2), Internal Memory 8GB (System 4GB + Available 4GB), Wi-Fi Built-in (802.11n combo), USB Cloning,
Easy Brightness Control, IDB App. (Whiteboard App.), Fail Over, Mirroring, SoftAP, Beacon, Embedded Template, Built-in Speaker (10W+10W), Crestron Connected**
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10% to 80%
POWER
Power Type Built-in Power Power Supply 100 -240V~, 50/60Hz
Power Consumption Typ./Max. 100W/115W Power Consumption Smart Energy Saving 70W
STANDARD(CERTIFICATION)
Safety UL/cUL/CB/TUV/KC EMC FCC Class "A"/CE/KCC
MEDIA PLAYER COMPATIBILITY
OPS type compatible Yes External Media player Attatchable Yes (MP500/MP700)
SOFTWARE COMPATIBILITY
Content Management Software SuperSign CMS Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (2ea batteries included), Power cord, QSG, RGB cable, Regulation book, Phone to RS232C gender, Memory cover Optional
Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSA), HDBaseT (EB-B100)
TOUCH
Touch type IR (Scattering) Scan Time 10 ms ?
Interface USB 2.0 Protection Glass Thickness 2.8T (Anti-Glare)
Operating Systme Support Windows 7, Windows 8/8.1/10, Mac OS X (10.7 or later), Android, Linux (kernel 3.9 or later) Multi touch point Max 10 Points
Floating Tool Bar
SoC and LG webOS
IDB App for Efficient Collaboration
LG FHD Technology
LG IPS Panel with Wide Viewing Angles and True Color
Auto Signal/Touch Switching
PANEL
Screen Size 109.22cm (43) Panel Technology IPS
Aspect Ratio 16 : 9 Native Resolution 1,920 x 1,080 (FHD)
Brightness (cd/m²) 450 Viewing Angle (HxV) 178 x 178
Response Time 12ms (G to G BW), 9.0ms (WOT) Surface Treatment Hard coating (3H), Anti-glare treatment of the front polarizer, (Haze 1%(Typ.))
Life Time (Typ.) 50,000Hrs Operation Hours 24Hrs
Orientation Landscape & Portrait
CONNECTIVITY
Input HDMI (2), DP, DVI-D, RGB, Audio In, USB 3.0 Output DP, Audio Out
External Control RS232C In/out, RJ45 In, IR Receiver In, Pixer Sensor In
PHYSICAL SPECIFICATION
Bezel Color Black Bezel Width 32.7 mm (Even)
Monitor Dimension (W x H x D) 1,278 x 748.8 x 71.4 mm Weight (Head) 28.0 kg
Carton Dimensions (W x H x D) 1,410 x 880 x 207 mm Packed Weight 33kg
VESA™ Standard Mount Interface 300 x 300 mm
SPECIAL FEATURES
Yes Temperature Sensor, Auto Brightness Sensor, Tile Mode (Up to 15x15), Natural Mode @Tile Mode, ISM Method, DPM Select, Energy Saving,
Smart Energy Saving, File Play with USB, PIP/PBP (2), Internal Memory 8GB (System 4GB + Available 4GB), Wi-Fi Built-in (802.11n combo), USB Cloning,
Easy Brightness Control, IDB App. (Whiteboard App.), Fail Over, Mirroring, SoftAP, Beacon, Embedded Template, Built-in Speaker (10W+10W), Crestron Connected**
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10% to 80%
POWER
Power Type Built-in Power Power Supply 100 -240V~, 50/60Hz
Power Consumption Typ./Max. 100W/115W Power Consumption Smart Energy Saving 70W
STANDARD(CERTIFICATION)
Safety UL/cUL/CB/TUV/KC EMC FCC Class "A"/CE/KCC
MEDIA PLAYER COMPATIBILITY
OPS type compatible Yes External Media player Attatchable Yes (MP500/MP700)
SOFTWARE COMPATIBILITY
Content Management Software SuperSign CMS Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (2ea batteries included), Power cord, QSG, RGB cable, Regulation book, Phone to RS232C gender, Memory cover Optional
Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSA), HDBaseT (EB-B100)
TOUCH
Touch type IR (Scattering) Scan Time 10 ms ?
Interface USB 2.0 Protection Glass Thickness 2.8T (Anti-Glare)
Operating Systme Support Windows 7, Windows 8/8.1/10, Mac OS X (10.7 or later), Android, Linux (kernel 3.9 or later) Multi touch point Max 10 Points
Floating Tool Bar
SoC and LG webOS
IDB App for Efficient Collaboration
LG FHD Technology
LG IPS Panel with Wide Viewing Angles and True Color
Auto Signal/Touch Switching
PANEL
Screen Size 124.46cm (49) Panel Technology IPS
Aspect Ratio 16 : 9 Native Resolution 1,920 x 1,080 (FHD)
Brightness (cd/m²) 450 Viewing Angle (HxV) 178 x 178
Response Time 12ms (G to G BW), 9.0ms (WOT) Surface Treatment Hard coating (3H), Anti-glare treatment of the front polarizer, (Haze 1%(Typ.))
Life Time (Typ.) 50,000Hrs Operation Hours 24Hrs
Orientation Landscape & Portrait
CONNECTIVITY
Input HDMI (2), DP, DVI-D, RGB, Audio In, USB 3.0 Output DP, Audio Out
External Control RS232C In/out, RJ45 In, IR Receiver In, Pixer Sensor In
PHYSICAL SPECIFICATION
Bezel Color Black Bezel Width 32.7 mm (Even)
Monitor Dimension (W x H x D) 1,278 x 748.8 x 71.4 mm Weight (Head) 28.0 kg
Carton Dimensions (W x H x D) 1,410 x 880 x 207 mm Packed Weight 33kg
VESA Standard Mount Interface 300 x 300 mm
SPECIAL FEATURES
Yes Temperature Sensor, Auto Brightness Sensor, Tile Mode (Up to 15x15), Natural Mode @Tile Mode, ISM Method, DPM Select, Energy Saving,
Smart Energy Saving, File Play with USB, PIP/PBP (2), Internal Memory 8GB (System 4GB + Available 4GB), Wi-Fi Built-in (802.11n combo), USB Cloning,
Easy Brightness Control, IDB App. (Whiteboard App.), Fail Over, Mirroring, SoftAP, Beacon, Embedded Template, Built-in Speaker (10W+10W), Crestron Connected**
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10% to 80%
POWER
Power Type Built-in Power Power Supply 100 -240V~, 50/60Hz
Power Consumption Typ./Max. 100W/115W Power Consumption Smart Energy Saving 70W
STANDARD(CERTIFICATION)
Safety UL/cUL/CB/TUV/KC EMC FCC Class "A"/CE/KCC
MEDIA PLAYER COMPATIBILITY
OPS type compatible Yes External Media player Attatchable Yes (MP500/MP700)
SOFTWARE COMPATIBILITY
Content Management Software SuperSign CMS Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (2ea batteries included), Power cord, QSG, RGB cable, Regulation book, Phone to RS232C gender, Memory cover Optional
Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSA), HDBaseT (EB-B100)
TOUCH
Touch type IR (Scattering) Scan Time 10 ms ?
Interface USB 2.0 Protection Glass Thickness 2.8T (Anti-Glare)
Operating Systme Support Windows 7, Windows 8/8.1/10, Mac OS X (10.7 or later), Android, Linux (kernel 3.9 or later) Multi touch point Max 10 Points
Floating Tool Bar
SoC and LG webOS
IDB App for Efficient Collaboration
LG FHD Technology
LG IPS Panel with Wide Viewing Angles and True Color
Auto Signal/Touch Switching
PANEL
Screen Size 139.7cm (55) Panel Technology IPS
Aspect Ratio 16 : 9 Native Resolution 1,920 x 1,080 (FHD)
Brightness (cd/m²) 450 Viewing Angle (HxV) 178 x 178
Response Time 12ms (G to G BW), 9.0ms (WOT) Surface Treatment Hard coating (3H), Anti-glare treatment of the front polarizer, (Haze 1%(Typ.))
Life Time (Typ.) 50,000Hrs Operation Hours 24Hrs
Orientation Landscape & Portrait
CONNECTIVITY
Input HDMI (2), DP, DVI-D, RGB, Audio In, USB 3.0 Output DP, Audio Out
External Control RS232C In/out, RJ45 In, IR Receiver In, Pixer Sensor In
PHYSICAL SPECIFICATION
Bezel Color Black Bezel Width 32.7 mm (Even)
Monitor Dimension (W x H x D) 1,278 x 748.8 x 71.4 mm Weight (Head) 28.0 kg
Carton Dimensions (W x H x D) 1,410 x 880 x 207 mm Packed Weight 33kg
VESA™ Standard Mount Interface 300 x 300 mm
SPECIAL FEATURES
Yes Temperature Sensor, Auto Brightness Sensor, Tile Mode (Up to 15x15), Natural Mode @Tile Mode, ISM Method, DPM Select, Energy Saving,
Smart Energy Saving, File Play with USB, PIP/PBP (2), Internal Memory 8GB (System 4GB + Available 4GB), Wi-Fi Built-in (802.11n combo), USB Cloning,
Easy Brightness Control, IDB App. (Whiteboard App.), Fail Over, Mirroring, SoftAP, Beacon, Embedded Template, Built-in Speaker (10W+10W), Crestron Connected**
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10% to 80%
POWER
Power Type Built-in Power Power Supply 100 -240V~, 50/60Hz
Power Consumption Typ./Max. 100W/115W Power Consumption Smart Energy Saving 70W
STANDARD(CERTIFICATION)
Safety UL/cUL/CB/TUV/KC EMC FCC Class "A"/CE/KCC
MEDIA PLAYER COMPATIBILITY
OPS type compatible Yes External Media player Attatchable Yes (MP500/MP700)
SOFTWARE COMPATIBILITY
Content Management Software SuperSign CMS Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (2ea batteries included), Power cord, QSG, RGB cable, Regulation book, Phone to RS232C gender, Memory cover Optional
Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSA), HDBaseT (EB-B100)
TOUCH
Touch type IR (Scattering) Scan Time 10 ms ?
Interface USB 2.0 Protection Glass Thickness 2.8T (Anti-Glare)
Operating Systme Support Windows 7, Windows 8/8.1/10, Mac OS X (10.7 or later), Android, Linux (kernel 3.9 or later) Multi touch point Max 10 Points
Brightness(Typ.) : 350 cd/m²
Touch Type : In-Cell
Multi Touch Point : Active Pen : Max 2 Point
Depth : 86.5 mm
Interface : HDMI (2), DP, DVI-D, USB Type C / Audio-in,RS232C In/Out,USB 2.0 (2), USB Type C(USB2.0), Touch Out(USB2.0,B Type)(2)
PANEL
Screen Size 218.44cm (86) Panel Technology IPS
Back Light Type Edge Aspect Ratio 16 : 9
Native Resolution 3,840 x 2,160 (UHD) Brightness(Typ., cd/m², w/ Protection Glass) 350
Contrast Ratio 1,000:1(TBD) Viewing Angle (H x V) 178 x 178
Response Time 8 ms(G to G) Life Time (Typ.) 30,000 Hrs (Min.)
Operation Hours 16Hr Orientation Landscape
CONNECTIVITY
Video / Audio HDMI (2), DP, DVI-D, USB External Control RS232C In/Out
USB USB 2.0 (2), USB Type C(USB2.0), Touch Out(USB2.0,B Type)(2)
MECHANICAL SPECIFICATION
Bezel Color Black Bezel Width (T/L/R/B) set: 28.8mm
Monitor Dimension (W × H × D) 1952.6 x 1164.1 x 86.4 mm Weight (Head) 66.7 kg
Carton Dimensions (W × H × D) 2190 x 1470 x 371 mm Packed Weight 95kg
Handle Yes VESA™ Standard Mount Interface 600 x 400
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10 % to 80 %
POWER
Power Supply 100-240V~, 50/60Hz Power Type Built-In Power
Power Consumption (Typ. / Max.) 360W / 420W
SOUND
Speaker Built in(10W/Ch)
STANDARD(CERTIFICATION)
Safety CB / NRTL EMC FCC Class "A" / CE / KC
MEDIA PLAYER COMPATIBILITY
OPS Type Compatible Yes Optional (OPS Kit (KT-OPSF))
ACCESSORY
Basic Remote Controller(include battery 2ea), Power Cord, QSG, HDMI(3M), Regulation Book, Phone to RS232C Gender, Touch Pen(2ea, include battery 2ea), Pen Tip(10ea), Tip Remover(2ea), USB Type-C Cable, Ferrite Core Filter
SPECIAL FEATURE
IDB App Yes
TOUCH SPECIFICATIONS
Touch Type In-cell Available Object Size for Touch Ø5 mm ?
Response Time (PC Windows 10) 70ms? Accuracy 1.5mm
Interface USB 2.0 Protection Glass Thickness 1.85T (Anti-Glare)
Protection Glass Transmission 88% Operating Systme Support Win7 professional, Win8.1, Win10
Multi touch point Finger : Max 20 Point (Windows), Finger: Max 10Point (webOS), Active Pen : Max 2 Point
TR3BF Series
Brightness(w/Protection Glass) : 330 cd/m²
Touch Type : IR
Multi Touch Point : Max 20 points / Max 10 writing
Interface : HDMI (3), RGB / Audio In,RS232C In, RJ45,USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update),
USB 3.0 (3), Touch Out(USB2.0,B Type) (2),HDMI (1), Optical Output / Audio Out
PANEL
Screen Size 65 Panel Technology IPS
Back Light Type Direct Aspect Ratio 16 : 9
Native Resolution 3,840 x 2,160 (UHD) Brightness(Typ., cd/m², w/ Protection Glass) 330
Contrast Ratio 1,100:1 Viewing Angle(H x V) 178 x 178
Response Time 8 ms (G to G) Life Time (Typ.) 30,000 Hrs (Min.)
Operation Hours 16Hr Orientation Landscape
CONNECTIVITY
(Input) Video / Audio HDMI (3), RGB / Audio In (Input) External Control RS232C In, RJ45
(Input) USB USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update), USB 3.0 (3), Touch Out(USB2.0,B Type) (2) (Output) Video / Audio HDMI (1), Optical Output / Audio Out
MECHANICAL SPECIFICATION
Bezel Color Black Bezel Width(Off Bezel) Top/Right/Left:17.7mm, Bottom:45.7mm
Monitor Dimension (W × H × D) 1,957×1,160×86mm Weight (Head) 67kg
Carton Dimensions(W x H x D) with pallet 2,230×1,499×285mm Packed Weight 109kg
Handle Yes VESA™ Standard Mount Interface 800 x 600
ENVIRONMENT CONDITIONS
Operation Temperature 0 °C to 40 °C Operation Humidity 10 % to 80 %
POWER
Power Supply 100 -240V~, 50/60Hz Power Type Built-In Power
Power Consumption (Typ. / Max.) 365W / 419W
SOUND
Speaker Built in 24W (12W + 12W)
STANDARD(CERTIFICATION)
Safety CB / NRTL EMC FCC Class "A" / CE
ErP / Energy Star Yes(EU Only) / No
MEDIA PLAYER COMPATIBILITY
OPS Type Compatible Yes
ACCESSORY
Basic Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Control
SPECIAL FEATURE
Embedded Writing Software Yes
TOUCH SPECIFICATIONS
Touch Type IR Available Object Size for Touch Ø3 mm ?
Response Time 60ms ? (Android) / 100ms ? (Windows) Accuracy 1.5mm
Interface USB 2.0 Protection Glass Thickness 4T (Anti-Glare)
Protection Glass Transmission 87% Operating System Support Windows 7/8/10/WindowsXP/Linux/Mac/Android (WindowsXP/Linux/Mac Support one point touch)
Multi touch point Max 20 points / Max 10 writing
TR3BF Series
Brightness(w/Protection Glass) : 330 cd/m²
Touch Type : IR
Multi Touch Point : Max 20 points / Max 10 writing
Interface : HDMI (3), RGB / Audio In,RS232C In, RJ45,USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update),
USB 3.0 (3), Touch Out(USB2.0,B Type) (2),HDMI (1), Optical Output / Audio Out
PANEL
Screen Size 75 Panel Technology IPS
Back Light Type Direct Aspect Ratio 16 : 9
Native Resolution 3,840 x 2,160 (UHD) Brightness(Typ., cd/m², w/ Protection Glass) 330
Contrast Ratio 1,100:1 Viewing Angle(H x V) 178 x 178
Response Time 8 ms (G to G) Life Time (Typ.) 30,000 Hrs (Min.)
Operation Hours 16Hr Orientation Landscape
CONNECTIVITY
(Input) Video / Audio HDMI (3), RGB / Audio In (Input) External Control RS232C In, RJ45
(Input) USB USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update), USB 3.0 (3), Touch Out(USB2.0,B Type) (2) (Output) Video / Audio HDMI (1), Optical Output / Audio Out
MECHANICAL SPECIFICATION
Bezel Color Black Bezel Width(Off Bezel) Top/Right/Left:17.7mm, Bottom:45.7mm
Monitor Dimension (W × H × D) 1,957×1,160×86mm Weight (Head) 67kg
Carton Dimensions(W x H x D) with pallet 2,230×1,499×285mm Packed Weight 109kg
Handle Yes VESA™ Standard Mount Interface 800 x 600
ENVIRONMENT CONDITIONS
Operation Temperature 0 °C to 40 °C Operation Humidity 10 % to 80 %
POWER
Power Supply 100 -240V~, 50/60Hz Power Type Built-In Power
Power Consumption (Typ. / Max.) 365W / 419W
SOUND
Speaker Built in 24W (12W + 12W)
STANDARD(CERTIFICATION)
Safety CB / NRTL EMC FCC Class "A" / CE
ErP / Energy Star Yes(EU Only) / No
MEDIA PLAYER COMPATIBILITY
OPS Type Compatible Yes
ACCESSORY
Basic Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Control
SPECIAL FEATURE
Embedded Writing Software Yes
TOUCH SPECIFICATIONS
Touch Type IR Available Object Size for Touch Ø3 mm ?
Response Time 60ms ? (Android) / 100ms ? (Windows) Accuracy 1.5mm
Interface USB 2.0 Protection Glass Thickness 4T (Anti-Glare)
Protection Glass Transmission 87% Operating System Support Windows 7/8/10/WindowsXP/Linux/Mac/Android (WindowsXP/Linux/Mac Support one point touch)
Multi touch point Max 20 points / Max 10 writing
TR3BF Series
Brightness(w/Protection Glass) : 330 cd/m²
Touch Type : IR
Multi Touch Point : Max 20 points / Max 10 writing
Interface : HDMI (3), RGB / Audio In,RS232C In, RJ45,USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update),
USB 3.0 (3), Touch Out(USB2.0,B Type) (2),HDMI (1), Optical Output / Audio Out
PANEL
Screen Size 86 Panel Technology IPS
Back Light Type Direct Aspect Ratio 16 : 9
Native Resolution 3,840 x 2,160 (UHD) Brightness(Typ., cd/m², w/ Protection Glass) 330
Contrast Ratio 1,100:1 Viewing Angle(H x V) 178 x 178
Response Time 8 ms (G to G) Life Time (Typ.) 30,000 Hrs (Min.)
Operation Hours 16Hr Orientation Landscape
CONNECTIVITY
(Input) Video / Audio HDMI (3), RGB / Audio In (Input) External Control RS232C In, RJ45
(Input) USB USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update), USB 3.0 (3), Touch Out(USB2.0,B Type) (2) (Output) Video / Audio HDMI (1), Optical Output / Audio Out
MECHANICAL SPECIFICATION
Bezel Color Black Bezel Width(Off Bezel) Top/Right/Left:17.7mm, Bottom:45.7mm
Monitor Dimension (W × H × D) 1,957×1,160×86mm Weight (Head) 67kg
Carton Dimensions(W x H x D) with pallet 2,230×1,499×285mm Packed Weight 109kg
Handle Yes VESA™ Standard Mount Interface 800 x 600
ENVIRONMENT CONDITIONS
Operation Temperature 0 °C to 40 °C Operation Humidity 10 % to 80 %
POWER
Power Supply 100 -240V~, 50/60Hz Power Type Built-In Power
Power Consumption (Typ. / Max.) 365W / 419W
SOUND
Speaker Built in 24W (12W + 12W)
STANDARD(CERTIFICATION)
Safety CB / NRTL EMC FCC Class "A" / CE
ErP / Energy Star Yes(EU Only) / No
MEDIA PLAYER COMPATIBILITY
OPS Type Compatible Yes
ACCESSORY
Basic Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Control
SPECIAL FEATURE
Embedded Writing Software Yes
TOUCH SPECIFICATIONS
Touch Type IR Available Object Size for Touch Ø3 mm ?
Response Time 60ms ? (Android) / 100ms ? (Windows) Accuracy 1.5mm
Interface USB 2.0 Protection Glass Thickness 4T (Anti-Glare)
Protection Glass Transmission 87% Operating System Support Windows 7/8/10/WindowsXP/Linux/Mac/Android (WindowsXP/Linux/Mac Support one point touch)
Multi touch point Max 20 points / Max 10 writing
Your Go-To Source for High-Performance IT Equipment
As leading interactive panel dealers in the IT hardware industry, we are committed to delivering reliable, high-performance server solutions that cater to the dynamic needs of modern businesses. Our extensive portfolio includes a wide range of servers—rack servers, tower servers, blade servers, and customized enterprise-grade systems—from globally recognized brands such as Dell, HP, Lenovo, Cisco, and more. Whether you are a small business looking for an entry-level server or a large enterprise seeking powerful, scalable data center infrastructure, we provide tailored solutions that align with your technical requirements and budget.
Our services go beyond just sales—we offer expert consultation to help clients choose the right server configurations based on workload, performance goals, and scalability. Each product we supply is rigorously tested for quality assurance and comes with warranty options and after-sales support, ensuring peace of mind and long-term performance. With a team of knowledgeable professionals, competitive pricing, and a customer-centric approach, we have established ourselves as a trusted partner for businesses, IT integrators, system administrators, and government organizations.
Whether you're upgrading your existing infrastructure, setting up a new data center, or integrating servers into a hybrid IT environment, our goal is to deliver dependable hardware solutions that empower your operations and drive digital transformation.
