General
Built-in Devices : Backplane
Hot-Swap Bays Qty : 10
Product Form Factor : Rack-mountable - 2U
Server Scalability : 2-way
Type : Server
Dimensions & Weight
Depth : 29.1 in
Height :3.4 in
Width : 17.6 in
Expansion / Connectivity
Bays : 10 (total) / 10 (free) x hot-swap 2.5" SFF
Interfaces : 2 x LAN (10Gigabit Ethernet) - RJ-45 ¦ 1 x KVM ¦ 1 x management ¦ 2 x USB 3.0 ¦ 1 x serial - RJ-45
Slots : 2 (total) / 2 (free) x CPU ¦ 24 (total) / 24 (free) x DIMM 288-pin ¦ 6 PCIe 3.0 ¦ 1 (total) / 1 (free) x PCIe ¦ 1 (total) / 1 (free) x mLOM ¦ 2 (total) / 2 (free) x M.2 Card ¦ 5 PCIe x8 ¦ 1 PCIe x16
Hard Drive
Type : No HDD
Manufacturer Warranty
Service & Support : Limited warranty - replacement - 3 years - response time: next business day
Networking
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Ethernet Controller : Intel X550
Optical Storage
Type : No optical drive
Power
Device Type : Power supply - hot-plug
Installed Qty : 0
Max Supported Qty : 2
Power Redundancy : Optional
Processor / Chipset
CPU No CPU
CPU Upgradability Upgradable
Max CPU Qty 2
RAM
Features : Registered, Load-Reduced DIMM (LRDIMM), through-silicon via DIMMs (TSV DIMMs)
Form Factor : DIMM 288-pin
Installed Size : 0 GB
Slots : 24 (total) / 24 (empty)
Technology : DDR4 SDRAM - ECC
Storage Controller
Channel Qty : 8
Controller Interface Type : SATA 3Gb/s
RAID Level : RAID 0, RAID 1, RAID 10
Type : RAID
