- Defend applications and data before your server is built with the new HPE Trusted Supply Chain offering.
- Supporting additional second generation Intel Xeon Scalable processor family offerings.
- Increased Single-Width GPU Density with up to 7 NVIDIA Tesla T4 16GB Computational Accelerators or 7 Xilinx Alveo U50 Accelerators supported in a standard-depth 2U rack form factor
- Networking Choice (NC) server models provide greater flexibility in the primary networking selection.
- Intel Optane persistent memory 100 series for HPE offers the flexibility to deploy as dense memory or fast storage and enables per-socket memory capacity of up to 3.0 TB.3
- iLO 5 security enhancements: Server Configuration Lock, iLO Security Dashboard and Workload Performance Advisor. HPE InfoSight provides cloud-based analytics to predict and prevent issues proactively.
Specification:
Management Software:
Infrastructure management: HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, and HPE OneView Advanced (optional; requires licenses)
Security:
Optional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0
Server Controllers:
Network controller: HPE 1 Gb 331i Ethernet adapter 4-ports per controller and/or optional HPE FlexibleLOM, depending on model
Storage controller: 1 HPE Smart Array S100i and/or 1 HPE Smart Array P408i-a and/or 1 HPE Smart Array P816i-a and/or 1 HPE Smart Array E208i-a, depending on model
Server Cooling:
System fan featuresHot-plug redundant fans, standard
Server Drives:
Drive supported8 or 12 LFF SAS/SATA/SSD 8, 10, 16, 18 or 24 SFF SAS/SATA/SSD; 2 M.2 SATA SSD standard on primary riser, depending on configuration; 6 SFF rear drive optional or 3 LFF rear drive optional and 2 SFF or 2 Dual UFF rear drive optional; 20 SFF NVMe optional; NVMe support via Express Bay will limit maximum drive capacity
Server Expansions:
Expansion slots: 8
Server Form Factor:
Form factor:2U Rack
Server Memory:
Memory type:HPE DDR4 Smart Memory with optional Intel® Optane™ persistent memory 100 series for HPE, depending on processor model selected. Intel Optane Persistent Memory for HPE only supported on select 2nd Generation Intel Scalable Series Processors, to include: 82xx, 62xxR, 62xx, 52xxR, 52xx series processors, and the 4215R and 4215 processors.
Maximum memory:3.0 TB with 128 GB DDR4, depending on processor model; 6.0 TB with HPE 512GB 2666 Persistent Memory Kit, depending on processor model
Memory slots:24 DIMM slots
NVDIMM type:HPE NVDIMM-N *Only available on 1st Generation Intel Xeon Scalable Processors
NVDIMM rank:Single rank
NVDIMM capacity:16 GB
Processor:
Processor type: Intel
Processor family: Intel Xeon Scalable 8100/8200 series Intel Xeon Scalable 6100/6200 series Intel Xeon Scalable 5100/5200 series Intel Xeon Scalable 4100/4200 series Intel Xeon Scalable 3100/3200 series
Processor number: 1 or 2
Processor core available4 to 28 core, depending on model
Processor speed3.9 GHz, maximum depending on processor
Processor cache8.25 - 38.50 MB L3, depending on processor model
Warranty:
Warranty3/3/3 - Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage.
Weights and Dimensions:
Weight:14.76 kg (32.6 lb)
Dimensions:44.55 x 73.03 x 8.74 cm (17.54 x 28.75 x 3.44 in)
